INSTALLATION INSTRUCTION
LED Step and Wall Lights - Trimless
WL-LED100TR
WARNING
IMPORTANT: NEVER attempt any work without shutting o the electricity.
- Read all instructions before installing.
- System is intended for installation by a qualied electrician in accordance with the National Electric Code and local
regulations. Consult with local inspector to ensure compliance.
- To reduce the risk of re, electrical shock and injuries to persons, turn o power at main switch before installing
or modifying the system.
- Retain instructions for future maintenance reference.
- Not complying with instructions could result in failure of the xtures and voiding of the warranty.
- This xture is intended to be installed in dry, indoor locations only!
INSTALLATION INSTRUCTIONS:
Junction box: 2” x 4” boxes to have minimum inside dimensions of 3”W x 2”H x 2”D in order to accommodate xtures.
Note: Actual depth of box to be determined in accordance with the NEC and local ordinances.
1. Install 2”x4” junction box.
2. Connect the xture wires to the junction box wires as follows: Black xture wire to black (Hot) J-box wire, white xture
wire to white (Neutral) J-box wire, and green xture wire to Ground. (See Fig.1)
Note: Multiple xtures (up to 200) can be wired together in parallel: Hot to hot, and neutral to neutral.
3. Place all wiring and connectors back in junction box and install the xture. (See Fig. 2)
4. Secure xture to J-box using (2) 8-32 at head screws (J-box by others, screws by WAC) as shown in Fig.2.
5. Spackle in xture and smooth/sand spackle so that xture is level with the rest of the wall. (See Fig. 3)
6. Paint wall and xture with desired color, leaving only the “ramp” painted white. (See Fig. 4)
