Seite 1/26
Page1of26
©Copyright 2018 WESCO Industrial Products, LLC. Specifications subject to change. Not responsible for errors or omissions.
TABLE OF CONTENTS
1 General Information ........................................................................................................................... 2
1.1 Description.............................................................................................................................. 2
1.2 Specifications.......................................................................................................................... 2
2 Safety Information................................................................................................................................ 2
3 Assembly.....……….............................................................................................................................. 2
4 Hydraulic Valve Adjustment................................................................................................................. 2
5 Operation.............................................................................................................................................. 4
6 Battery Charging & Replacement......................................................................................................... 5
7 Maintenance......................................................................................................................................... 7
8 Trouble Shooting.................................................................................................................................. 8
9 Hydraulic & Circuit Diagrams............................................................................................................... 9
9.1 Hydraulic Flow Diagram (Models Manufactured Before 2010)................................................ 9
9.2 Circuit Diagram (Models Manufactured Before 2010).............................................................. 9
9.3 Hydraulic Flow Diagram (Models Manufactured Between 2010 & 2015)................................. 10
9.4 Circuit Diagram (Models Manufactured Between 2010 & 2015).............................................. 10
9.5 Hydraulic Flow Diagram (Models Manufactured After 2015)................................................... 11
9.5 Circuit Diagram (Models Manufactured After 2015)................................................................. 11
10 Part Information (Models Manufactured Before 2010)......................................................................... 12
10.1 Handle Part Diagram................................................................................................................ 12
10.2 Handle Part List........................................................................................................................ 12
10.3 Frame Part Diagram................................................................................................................. 13
10.4 Frame Part List......................................................................................................................... 13
10.5 Pump Part Diagram.................................................................................................................. 14
10.6 Pump Part List.......................................................................................................................... 14
10.7 Steer Wheel Assembly Part Diagram....................................................................................... 15
10.8 Steer Wheel Assembly Part List............................................................................................... 16
10 Part Information (Models Manufactured Between 2010 & 2015)......................................................... 17
10.1 Frame & Handle Part Diagram................................................................................................. 17
10.2 Frame & Handle Part List......................................................................................................... 18
10.3 Pump Part Diagram.................................................................................................................. 19
10.4 Pump Part List.......................................................................................................................... 20
11 Part Information (Models Manufactured After 2015)............................................................................ 21
11.1 Handle Part Diagram................................................................................................................ 21
11.2 Handle Part List........................................................................................................................ 21
11.3 Frame Part Diagram................................................................................................................. 22
11.4 Frame Part List......................................................................................................................... 22
11.5 Pump Part Diagram.................................................................................................................. 23
11.6 Pump Part List.......................................................................................................................... 24
11.7 External Charger Part Diagram................................................................................................ 25
11.8 External Charger Part List........................................................................................................ 26
WESCOINDUSTRIALPRODUCTS,LLC
InstructionManual
ElectricNon‐TelescopingHighLiftTruck
PartNumber: 272460&272461
Note: Operator MUST read and understand these operating instructions before using
this High Lift Truck.
Page2of26
©Copyright 2018 WESCO Industrial Products, LLC. Specifications subject to change. Not responsible for errors or omissions.
Electric Non-Telescoping High Lift Truck
(Part # 272460 & 272461)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR HIGH LIFT TRUCK,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
WARNING: The battery in this product contains lead. The State of California under
Proposition 65 has determined that exposure to lead is known to cause cancer or birth
defects or other reproductive harm. Please wash hands after use.
1. GENERAL INFORMATION
1.1 DESCRIPTION
Thank you for purchasing an Electric Non-Telescoping High Lift Truck. This truck has been
designed for transporting and horizontal lifting of loads of up to 2,200 lbs.
The electric high lift trucks
feature a one year pump warranty and a battery powered hydraulic lift system that is operated with fingertip
controls. It can greatly reduce labor and increase working efficiency and is an efficient tool for various work
environments.
1.2 SPECIFICATIONS
Model 272460 272461
Capacity 2,200 lbs 2,200 lbs
Weight 367 lbs 372 lbs
Fork Lowered Height 3.3” 3.3”
Fork Raised Height 31” 31”
Single Fork Width 6.5” 6.5”
Fork Length 45” 45”
Overall Width 21” 27”
Overall Length 60” 63”
Overall Height 48.5” 48.5”
Telescoping No No
Steering & Load Wheels Polyurethane Polyurethane
Materials and specifications are subject to change without notice.
2. SAFETY INFORMATION
1) Read the manual carefully before operation. Go through every procedure as required in the
manual.
2) Lift the fork to its full range a few times before use to release the air in the hydraulic system.
3) Do not lift or pull personnel with the truck.
4) Do not operate the unit on sloped or tilted surfaces.
5) Do not put your hand or foot under the fork or into the moving parts
6) Put all loads in the center of the fork.
7) The safety valve in the pump station will automatically open when the unit becomes overloaded. If
this occurs, don’t try to lift the load any more by pushing the “UP” button. This will reduce the
lifespan of the pump unit.
8) Power off the unit when not in use.
9) To replace or fill hydraulic oil, the fork should be lowered to its lowest position. The oil to be used
should be clean and filtered. The condensation point of the oil should be ≤ -4˚F (-20˚C), and the
motion viscosity should be 20–30 cst.
Note: Hydraulic Oil ISO VG 32 and multipurpose lubricating grease ZG2# or 3# are recommended
for maintenance of this unit.
