Seite 1/24
PRODUCT DESCRIPTION
CONTROL PANEL
1. Control panel
2. Fan
3. Circular heating element
(not visible)
4. Shelf guides
(the level is indicated on the front
of the oven)
5. Door
6. Upper heating element/grill
7. Lamp
8. Meat probe insert point
(if present)
9. Identification plate
(do not remove)
10. Lower heating element
(not visible)
1. LEFT-HAND DISPLAY
2. LIGHT
For switching the lamp on/off.
3. ON/OFF
For switching the oven on and off
and for stopping an active function
at any time.
4. BACK
For returning to the previous menu
when configuring settings.
5. ROTARY KNOB / 6TH SENSE
BUTTON
Turn this to navigate through the
functions and adjust all of the
cooking parameters. Press
to select, set, access or confirm
functions or parameters and
eventually start the cooking
program.
6. TEMPERATURE
For setting the temperature.
7. TIME
For setting or changing the time
and adjusting the cooking time.
8. START
For starting functions and
confirming settings.
9. RIGHT-HAND DISPLAY
DAILY REFERENCE
GUIDE
Before using the appliance carefully read the Health and Safety guide.
THANK YOU FOR PURCHASING A
WHIRLPOOL PRODUCT
To receive more comprehensive help and
support, please register your product at
www.whirlpool.eu/register
WWW
You can download the Safety Instructions
and the Use and Care Guide by visiting our
website docs.whirlpool.eu and following
the instructions on the back of this booklet.
5
4
3
2
1
5
4
3
2
1
1
2
3
4
5
9
10
7
6
1 2 5 6 934 78
8
EN 7
ACCESSORIES
WIRE SHELF DRIP TRAY BAKING TRAY
SLIDING RUNNERS *
(ONLY IN SOME MODELS)
MEAT PROBE
(ONLY IN SOME MODELS)
The number of accessories may vary depending on which
model is purchased.
Other accessories can be purchased separately from the
After-sales Service.
INSERTING THE WIRE SHELF AND OTHER
ACCESSORIES
Insert the wire shelf horizontally by sliding it across
the shelf guides, making sure that the side with the
raised edge is facing upwards.
Other accessories, such as the drip tray and the
baking tray, are inserted horizontally in the same way
as the wire shelf.
FITTING THE SLIDING RUNNERS
(IF PRESENT)
Remove the shelf guides from the oven and remove
the protective plastic from the sliding runners.
Fasten the upper clip of the
runner to the shelf guide
and slide it along as far as it
will go. Lower the other clip
into position.
To secure the guide, press
the lower portion of the
clip firmly against the shelf
guide. Make sure that the
runners can move freely.
Repeat these steps on the
other shelf guide on the
same level.
Please note: The sliding runners can be tted on any level.
EN 8
REMOVING AND REFITTING THE SHELF GUIDES
See pictures (Fig. 1, 2, 3) to remove lateral supports
and (if present) cavity nuts that retain the same.
To refit the shelf guides, first fit them back into their
upper seating. Keeping them held up, slide them into
the cooking compartment, then lower them into
position in the lower seating.
2
1
