Whirlpool FFT M22 8X3B SPT Bedienungsanleitung
Seiten 12 Trockner
Lies die Bedienungsanleitung für Whirlpool FFT M22 8X3B SPT kostenlos online oder lade das PDF herunter. 34 Personen fanden diese Anleitung hilfreich. Frage zu diesem Modell? Stelle eine Frage
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register
EN
PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.
Quick guide
Before using the appliance carefully
read the Safety Instruction.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying
cycle.
- remember to clean your lters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door lter. Do not load items that
are dripping wet. Do not tumble dry large, very bulky items. For
optimal drying result, garments should be loaded one by one.
3. Close the door.
4. Press the "On/O" button.
5. Select the most suitable programme
for the type of fabric in
that load.
6. Select the options, if necessary.
7. Press the "
Start/Pause"
button to begin drying.
8. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Turn the machine
o by pressing the "On/O" button, open the door and pull the
clothing immediately out to prevent the formation of creases on
laundry.
If the machine is not switched o manually, after about a quarter
of an hour from the end of the cycle , the appliance turns o
automatically to save energy.
Note that some models perform a nal cool tumble phase, for this
reason the fabrics may not feel hot.
In case of power failure, it is necessary to press the "Start/Pause"
button to restart the cycle
Opening the door during the cycle
The tumble dryer door can be opened at any time during the cycle
to check progress and remove any garments already dry.
However, since opening the door can extend the drying time, the
recommendation is to keep the door closed throughout the cycle
process to save time and energy.
After closing the door, press the "Start/Pause" button within 15
minutes to resume the machine operation.
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dryer is xed correctly,
either to the dryer’s water tank, or to your domestic drainage
system.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
Before you use your dryer ensure that it has been in a upright
position for at least 6 hours.
CONTROL PANEL
1 ON/OFF button (hold for Reset)
2 Programme selection Knob
3 Start/Pause
Options Buttons*
4 Cycle end
5 High heat
6 Anti tangle Mute)(hold for
7 Dryness level
8 Start delay
9 Timed drying
10 Rapid Key lock)(hold for
11 Gentle
12 FreshCare+
*Note: some models may have the wording in full instead of the icons.
INDICATORS
Dryness level: Iron dry - Hanger dry - Cupboard dry - Extra dry
Cycle phase:
Drying - Cool down - End of cycle
Empty water tank- - Clean door lter Clean bottom lter
Refer to troubleshooting section: Failure: Call after sales service
1
3
2
12
10
11
789
3“
3“
h
6
5
4
Produktspezifikationen
| Marke: | Whirlpool |
| Kategorie: | Trockner |
| Modell: | FFT M22 8X3B SPT |
| Display-Typ: | LED |
| Breite: | 595 mm |
| Tiefe: | 649 mm |
| Gewicht: | 44000 g |
| Produktfarbe: | Weiß |
| Steuerung: | Buttons, Rotary |
| Höhe: | 849 mm |
| AC Eingangsspannung: | 220 - 240 V |
| AC Eingangsfrequenz: | 50 Hz |
| Eingebautes Display: | Ja |
| Geräteplatzierung: | Freistehend |
| Kabellänge: | 1.5 m |
| Energieeffizienzskala: | A+++ bis D |
| Trockenprogramme: | Colour, Cotton, Delicate/silk, Freshen-up, Gentle care, Mix, Quick, Synthetics |
| Startzeitvorwahl: | Ja |
| Ladetyp: | Frontlader |
| Anschlusswert: | 700 W |
| Stromstärke: | 10 A |
| Jährlicher Energieverbrauch: | 175 kWh |
| Wärmequelle: | Elektro |
| Energieverbrauch: | - kWh |
| Zykluszeit: | 165 min |
| Nennkapazität: | 8 kg |
| Geräuschpegel: | 64 dB |
| Türanschlag: | Rechts |
| Türfarbe: | Schwarz |
| Trocknungssystem: | Kondensation |
| Einschalteverzögerung (max.): | 24 h |
| Kindersicherung: | Ja |
| Benutzerdefinierte Panel-Bereitschaft: | Ja |
| Trommelvolumen: | 120 l |
| Feuchtigkeitssensor: | Ja |
| Betriebsbereitschaftsanzeige: | Ja |
| Türstil: | Glastür |
| Anzeige Wassertank voll: | Ja |
