Whirlpool W7X 93T KS Bedienungsanleitung

Whirlpool Kühlschrank W7X 93T KS

Lies die bedienungsanleitung für Whirlpool W7X 93T KS (36 Seiten) kostenlos online; sie gehört zur Kategorie Kühlschrank. Dieses Handbuch wurde von 4 Personen als hilfreich bewertet und erhielt im Schnitt 4.4 Sterne aus 2.5 Bewertungen. Hast du eine Frage zu Whirlpool W7X 93T KS oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage

Download PDF

Seite 1/36

Quick guide

* Available only on certain models

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

FIRST TIME USE

After installation, wait at least two hours before connecting the appliance to

the power supply. Once connected, it will start working automatically. The

ideal temperature settings are preset from the factory.

After turning the appliance on, wait 4-6 hours for it to reach the correct food

storage temperature.

CONTROL PANEL

1. On/o

2. Fast Cool button

3. Fridge temperature setting

4. Refrigerator temperature display

5. Alarm

6. Freezer temperature display

7. Freezer temperature setting

8. Fast Freeze

9. ECO / ECOPlus

10. Good Night

ON/OFF

To switch on/switch o the product press on/o on the display.

FAST COOL FUNCTION

You can enable or disable the Fast Cool feature (quick cooling of both fresh

and just cooked food) by pressing the Fast Cool key on the display. The Fast

Cool led turns on when activated. The function is automatically disabled

after 12 hours, or can be manually disabled by pressing the Fast Cool button.

FRIDGE TEMPERATURE SETTING

Used to modify the temperature setting of the refrigerator. Conrmation

corresponding to the selected temperature appears on the display.

Recommended setting for the refrigerator compartment is +4°C.

ALARM

An alarm situation has been detected in the product (see alarm table).

REFRIGERATOR TEMPERATURE DISPLAY

Shows the set temperature for the refrigerator compartment.

FREEZER TEMPERATURE DISPLAY

Shows the set temperature for the freezer compartment.

FREEZER TEMPERATURE SETTING

Used to modify the temperature setting of the freezer. Conrmation

corresponding to the selected temperature appears on the display.

Recommended setting for the freezer compartment is -18°C.

FAST FREEZE FUNCTION

This function is recommended for freezing fresh food. Fresh food should

be frozen as quickly as possible, for the best possible preservation and for

keeping its nutritional value. Press the Fast Freeze key when you need to

freeze fresh food, the Fast Freeze indicator will come on. We recommend

you press the Fast Freeze key 24 hours before putting the food in, in order to

prepare the freezer compartment for the best possible freezing conditions.

We recommend you use the bottom drawer to maximize the freezing

capacity. The Fast Freeze function is automatically deactivated after 48

hours, or you can disable it manually by pressing the Fast Freeze key.

ECO

You can use this function to optimize energy consumption of the product.

Activate or deactivate the ECO function by pressing the ECO key on the

display. The light of the ECO on the display is on when activated. The

temperature values +5°C and -18°C appear on the refrigerator and freezer

displays respectively.

Note: The ECO key can enable ECOPlus function.

ECOPLUS

You can use this function to decrease energy consumption of the product

by blanking the control panel when no interaction is needed. To activate the

ECOPlus function press and hold the ECO key for 8 seconds. After 5 seconds

from activation all the digits and LED light switch o, except for the ECO

light that keeps blinking. You can press any key to wake up the display and

make your adjustments. 5 seconds after no interaction, the display returns

to ECOPlus mode. Deactivate the ECOPlus function using ON/OFF key or

press any other function key.

GOOD NIGHT

The Good Night function makes it possible to minimize any noise, at the

same time ensuring suitable storage performance.

The compressor will be working at the minimum speed that can be set.

When you start the function, the display enters into standby mode and

the relevant Good Night icon lights up. The Good Night function can

automatically stop either after maximum 6 hours or after the performance

of the product with the function ON can no longer be ensured owing to a

number of dierent reasons.

To stop the function manually press the button again or switch o the

device - we recommend starting the function in the night hours or

minimizing any interaction with the fridge to prevent the function from

stopping automatically.

LED LIGHT

This product contains a light source of energy eciency class F.

If the LED light system does not work, please contact the Service to replace

it.

Important: The refrigerator compartment light switches on when the

refrigerator door is opened. If the door is kept open for more than 8 minutes

the light will be automatically switched o.

HOW TO STORE FRESH FOOD AND BEVERAGES

a) b)

* The number and type of door balconies depends on the model

Legend

TEMPERATE ZONE

Suggested for storage of tropical fruit, cans, drinks,

eggs, sauces, pickles, butter, jam

COOL ZONE

Suggested for the storage of cheese, milk, daily

food, delicatessen, yogurt

COOLEST AREA

a) Suggested for storage of cold cuts, desserts, meat

and sh

b) Suggested for storage of sh, meat, cheese, dairy

products, fruits, vegetables.

The drawer available only on certain models

FRUIT & VEGETABLE DRAWER

FREEZER DRAWERS

(One drawer in models lower than 1,7m)

FREEZING ZONE DRAWER

(Max cool zone)

Suggested to freeze fresh / cooked food

REFRIGERATION COMPARTMENT

Refrigerator compartment defrosting is completely automatic.

Droplets of water on the rear wall inside the refrigerator compartment

indicate that the automatic defrost phase is in progress.

The defrost water is automatically run into a drain hole and collected in

a container, where it evaporates.

Multi-fresh Zone (drawer)*

You can customize the temperature in the Multi-fresh Zone (b) to

preserve the type of food you place inside as best possible.

Turn the knob on the drawer to set the food type:

• Fish and meat*

• Cheese and dairy products

• Fruit and vegetables

Note: we recommend you do not put sh and meat inside the drawer at

the same time unless they are properly packed, to avoid cross

contamination.

Humidity Control*

Turn the knob to the left if you are storing vegetables (for which a

more humid environment is recommended), rotate the knob to the

right if you are storing fruit (for which a less humid environment

is recommended), turn the knob to the middle if you are storing a

mixture of fruit and vegetables.

Foldable shelf*

This shelf can be used in three dierent ways:

1. Full-depth, to use the entire surface.

Half-depth, to use the rear part and at the same time create space

for taller items (like bottles and jugs) on the shelf below. To adjust

the shelf to half-depth, slightly raise the front part then pull it in.

Flipped up if you need to make space for tall or bulky items on the

shelf below. To ip the shelf up, rst adjust it to the halfway

* Available only on certain models

6th SENSE

This function automatically works to ensure the optimal conditions to

preserve the stored food. The “6th Sense” function is automatically activated

when:

• a large amount of food is loaded into the refrigerator

• the refrigerator door is left open for a long time

• a prolonged power failure takes place, causing the internal temperature

of the appliance to increase to values that cannot guarantee safe

storage of food.

Produktspezifikationen

Marke:	Whirlpool
Kategorie:	Kühlschrank
Modell:	W7X 93T KS
Breite:	596 mm
Tiefe:	678 mm
Gewicht:	75000 g
Produktfarbe:	Black, Stainless steel
Steuerung:	Berührung
Höhe:	2027 mm
AC Eingangsspannung:	220 - 240 V
AC Eingangsfrequenz:	50 Hz
Eingebautes Display:	Ja
Verpackungsbreite:	640 mm
Verpackungstiefe:	760 mm
Verpackungshöhe:	2080 mm
Paketgewicht:	78000 g
Geräteplatzierung:	Freistehend
Energieeffizienzklasse:	D
Kabellänge:	1.6 m
Energieeffizienzskala:	A bis G
Anschlusswert:	160 W
Stromstärke:	1 A
Nutzinhalt Gesamteinheit:	367 l
Minimale Betriebstemperatur:	10 °C
Maximale Betriebstemperatur:	43 °C
Nutzinhalt Kühlschrank:	263 l
Kühlschrank - Anzahl der Ablagen/Körbe:	5
Jährlicher Energieverbrauch:	203 kWh
Geräuschpegel:	34 dB
Türanschlag:	Rechts
Wechselbare Türen:	Ja
Gefrierfach - Anzahl der Ablagen/Körbe:	3
Regalmaterial:	Glas
Nutzinhalt Gefrierfach:	104 l
Gefrierkapazität:	11 kg/24h
Lagerzeit bei Störung:	11 h
Sternekennzeichnung:	4*
Klimaklasse:	SN-T
Abtauautomatik (Gefriereinheit):	Ja
Lampentyp:	LED
Türschließ-Erinnerungs-Alarm:	Ja
Temperaturalarm:	Ja
Lärmemissionsklasse:	B
Einstellbare Regale:	Ja
Innenbeleuchtung Kühleinheit:	Ja
Multi Airflow System (Kühlschrank):	Ja
NoFrost-Funktion (Kühleinheit):	Ja
Anzahl der Gemüseschubladen:	1
Ablageflächen Kühlschranktür:	5
Flaschengestelle:	Ja
Super Kühlungs-Funktion:	Ja
Gefrierfachposition:	Unten
NoFrost-Funktion (Gefriereinheit):	Ja
Schnellfrost-Funktion:	Ja
Fresh Zone Fach:	Ja
Anzahl der Kompressoren:	1
Abtauautomatik (Kühleinheit):	Ja
Eiswürfelbereiter:	Nein
Fresh Converter:	Ja
Anzahl der Türen:	2 Tür(en)
Flaschenfach in der Tür:	Ja
Urlaubsschaltung:	Nein
Wasserspender:	Nein
Kühlsystem:	Dynamisch (lüfterunterstützt)
Antibakterielles Fach:	Nein
Belüftung:	Nein
Eingelassene(r) Griff(e):	Ja
Elektronische Steuerung:	Ja
Gewährleistungsfrist:	2 Jahr(e)
Mittleres Fach:	Nein
