Whirlpool WT70E 831 X Bedienungsanleitung

Whirlpool Kühlschrank WT70E 831 X

Lies die bedienungsanleitung für Whirlpool WT70E 831 X (100 Seiten) kostenlos online; sie gehört zur Kategorie Kühlschrank. Dieses Handbuch wurde von 3 Personen als hilfreich bewertet und erhielt im Schnitt 3.6 Sterne aus 2 Bewertungen. Hast du eine Frage zu Whirlpool WT70E 831 X oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage

Download PDF

Seite 1/100

Quick guide

1. On/O

2. Fridge temperature indicator

3. Fridge temperature setting

4. Fast freeze indicator light

5. Fast freeze button

PRODUCT DESCRIPTION

APPLIANCE

CONTROL PANEL

1. Ice Device*

2. Quick Freezer*

3. Freezer And Storage Compartment

4. Food Care Zone 0°C/

Safe Defrost*

5. Shelves*

6. Bottle Rack*

7. Fruit And Vegetable Bin*

8. Movable Shelves*

9. Temperature Indicator*

10. Dairy Shelf*

11. Bottle Shelf

12. Levelling Feet

* Varies by number and/or position,

available only on certain models.

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

* Available only on certain models

ACCESSORIES

EASY ICE BOTTLE RACK

FIRST TIME USE

HOW TO START THE APPLIANCE

After plugging the appliance to the mains, it starts the

operation automatically. After starting the appliance, wait at

least 4-6 hours before placing food into the fridge and into

the freezer compartment.

When the appliance is connected to the power supply, the

display lights up and all the icons appear on the display for

approximately 1 second. The default (factory) values of the

fridge - freezer compartment settings light-up.

DAILY USE

FUNCTIONS

ON/OFF

The whole product (both fridge and freezer compartments)

can be turned on by pressing this button for 2 seconds.

The last set value is indicated on the interface. Press this

button to turn o the device. An audible signal will conrm

the “o commutation of the product”.

FRIDGE TEMPERATURE

To adjust the Fridge Temperature, press the Fridge °C button.

The Fridge Temperature can be adjusted between +2°C and

+8°C, as shown by the Fridge Temperature LEDs. It shows

the temperature of the fridge compartment. It allows you to

change the fridge temperature value, in a cyclical way; it also

conrms the selected temperature on the interface.

FAST FREEZE BUTTON

Fast freezing is to be used to freeze fresh foods. When it is

pressed, the Fast cool indicator light illuminates.

TEMPERATURE INDICATOR*

Temperature indicator informs you if the temperature in this

cavity is cold enough for storage with the word “OK”.

1. Check that OK appears clearly on the indicator light (see

the picture below).

If the word “OK” does not appear it means that the

temperature is too high: set a lower temperature and wait

approximately 10 hours until the temperature has been

stabilised.

3. Check the indicator light again: if necessary, readjust it

following the initial process. If large quantities of food have

been added or if the refrigerator door has been opened

frequently, it is normal for the indicator not to show OK.

Wait at least 10 hours before adjusting the REFRIGERATOR

OPERATION knob to a higher setting.

FOOD CARE ZONE 0°C / SAFE DEFROST*

A compartment designed to keep delicate food such as meat

and sh fresh. The low temperature in the compartment

makes it possible to store the food for up to one week -

tests performed on meat products - without changing its

nutrients, appearance and avour.

The compartment is also very suitable for healthy food

defrosting, as low-temperature defrosting prevents any

proliferation of microorganisms, while protecting its taste

and organoleptic properties.

It is not suitable for fruit, vegetables and green salad. But it

can be used for stued fresh pasta and even cooked food or

leftovers.

See Use and Care Guide for more details on functions / see last

page for information on how to obtain the Use and Care Guide

* Available only on certain models

Produktspezifikationen

Marke:	Whirlpool
Kategorie:	Kühlschrank
Modell:	WT70E 831 X
Breite:	700 mm
Tiefe:	725 mm
Gewicht:	78000 g
Produktfarbe:	Edelstahl
Höhe:	1800 mm
AC Eingangsspannung:	220 - 240 V
AC Eingangsfrequenz:	50 Hz
Eingebautes Display:	Ja
Geräteplatzierung:	Freistehend
Energieeffizienzklasse:	F
Kabellänge:	2.17 m
Energieeffizienzskala:	A bis G
Verstellbare Füße:	Ja
Anschlusswert:	- W
Stromstärke:	1.5 A
Nutzinhalt Gesamteinheit:	419 l
Minimale Betriebstemperatur:	16 °C
Maximale Betriebstemperatur:	32 °C
Nutzinhalt Kühlschrank:	313 l
Kühlschrank - Anzahl der Ablagen/Körbe:	4
Jährlicher Energieverbrauch:	320 kWh
Geräuschpegel:	43 dB
Türanschlag:	Rechts
Wechselbare Türen:	Ja
Gefrierfach - Anzahl der Ablagen/Körbe:	3
Regalmaterial:	Glas
Nutzinhalt Gefrierfach:	106 l
Bruttokapazität Gefrierfach:	110 l
Gefrierkapazität:	7 kg/24h
Lagerzeit bei Störung:	16 h
Sternekennzeichnung:	4*
Lärmemissionsklasse:	D
NoFrost-Funktion (Kühleinheit):	Ja
Anzahl der herausnehmbaren Einlegeböden:	3
Anzahl der Gemüseschubladen:	2
Ablageflächen Kühlschranktür:	3
Super Kühlungs-Funktion:	Nein
Gefrierfachposition:	Oben
NoFrost-Funktion (Gefriereinheit):	Ja
Schnellfrost-Funktion:	Ja
Fresh Zone Fach:	Ja
Ausfallalarm:	Nein
Bruttokapazität Kühlschrank:	325 l
Abtauautomatik (Kühleinheit):	Ja
Bruttokapazität Gesamteinheit:	435 l
Anti-Fingerprint Oberfläche:	Ja
Eiswürfelbereiter:	Ja
Wasserspender:	Ja
Belüftung:	Nein
Ablageflächen Tür Gefriereinheit:	2
Elektronische Steuerung:	Ja
Fehleranzeige:	Ja
