SCALING POLARIZER 1 & 2

Use these controls to change the of the respective input signals.amplitude and polarity

Center position (0) turns the respective input signal level o.

Maximum position (+) results in the full, normal signal.

Minimum position (-) results in the full, inverted signal.

OFFSET 1 & 2

Use these controls to to the respective input signals. This control will add a (+/-5V) DC oset

send a bipolar DC oset to the output whether or not a signal is applied to one of the

inputs.

Center position (0) turns the oset level o.

Maximum position (+) results in the full, (+5V) positive oset signal.

Minimum position (-) results in the full, (-5V) inverted oset signal.

S.P.O. is a polarizing scaler and oset generator. Up to two inputs can be summed into a single

scaler/oset generator. The oset generator provides a DC oset for shifting signals into the

positive or negative voltage region. The scaler provides a means of attenuating and polarizing

(inverting) the applied signal. S.P.O. works with audio and control voltages (CV).

SUMMING INPUTS 1 & 2

These are the respective inputs to the polarizers and oset generators. There are two

inputs each. Applying two signals will sumthem together. Both audio and control

voltages (CV) can be utilized.

BIPOLAR LEVEL LED 1 & 2

These LEDs indicate of the polarity of the input signal and/or oset. BLUE is positive and

RED is negative.

OUT

PANEL CONTROL

LED INDICATOR

INPUT

OUTPUT

COLOR KEY LEGEND

OUTPUTS 1 & 2

These are the respective outputs for each polarizer/oset generator.

OF1

SP1

SP2

OF2

IN 1

A+B

IN 2

A+B

2

OUT

1

SP2

OF1

OF2

IN 1

A+B

IN 2

A+B

OUT

1

OUT

2

IN 1

OUT

+

+

SP 1

SIGNAL PATH DIAGRAM

A

IN 1

B

Σ

OF 1

1

+

IN 2

OUT

+

+

SP 2

A

IN 2

B

Σ

OF 2

2

+

Σ

= SUM
