IMPORTANT! Installation Requirements
• Visit the NetworkHD product pages download section at wyrestorm.
com to check for the latest rmware, document versions, and WyreStorm
Management Suite conguration tools.
• Install the latest rmware onto all encoders and decoders using the
Maintenance Tool found in the Management Suite and via the NHD-000-
CTL web interface. Full rmware update instructions are included with the
rmware download.
• NetworkHD requires a Layer 2+ or Layer 3 managed switch network with
support for Multicast & IGMP snooping enabled.
• WyreStorm highly recommends using network switches listed in the
NetworkHD Switch Recommendation Guide. These switches have been
veried by WyreStorm to meet the requirements of a NetworkHD system.
• Congure all network switches to the exact specication of the guides at
wyrestorm.com prior to connecting any NetworkHD devices.
• NetworkHD uses stateless address autoconguration (auto-IP) to assign
link-local IP addresses in the range of 169.254.x.x to encoders and
decoders out of the box. Your PC must be set to an address in this range in
order to discover the encoders, decoders and NHD-000-CTL.
• WyreStorm recommends the use of the NHD-000-RACK4 for installations
containing multiple NetworkHD devices. Use of this product provides an
enclosure to mount and secure all NetworkHD devices in a standard 19-
inch rack frame (EIA-310).
Copyright © 2019 WyreStorm Technologies | wyrestorm.com
NHD-400-TX-IW Quickstart Guide | 190115
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
1 of 4
Basic Wiring Diagram
Wifi Router
Control
System
Personal Computer
Analog
Video
Analog
Audio
Analog Audio
HDMI
HDMI
NHD-400-RXNHD-400-RXNHD-400-RX
iPad with
NetworkHD Touch™
UHD Blu-ray Player
NHD-000-CTL
Key
Digital Video/DVI/HDMI
Ethernet
Control
Analog Video
Analog Audio
NHD-400-TX-IWNHD-400-TX-IW
NHD-400-TX
UHD Satellite Box
IR
RS-232
IR
Audio Distribution
Amplifier
400 Series In-Wall 4K AV over IP JPEG 2000 Encoder
NHD-400-TX-IW
Quickstart Guide
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the
installation process.
Box Contents
1x NHD-400-TX-IW Encoder
1x 12V DC Power Supply (US | UK | EU)
1x 2-Pin Terminal Block
1x 3.5mm Stereo TRS Plug to 3-pin Terminal Block RS-232 Adapter
1x White Decorative Plate with 4 Screws
1x Quick Start Guide (This Document)
Additional Information
More information and required software can be found within the Download
section of the product page onwyrestorm.com.
• Management Suite v1.4 or Higher
• NetworkHD Switch Recommendations
• NetworkHD Switch Mapping Worksheet
• NetworkHD Switch Conguration Guides
• NetworkHD Touch Installation Guide
• NetworkHD Touch User Guide
• Drivers for Popular Control Systems
