1The installation of this unit demands carefully performed work, so take

care in terms of safety during the installation. Read this install manual

carefully prior to starting the assembly and installation work. Yamaha

shall not bear any responsibility for any accidents or injury that occur due

to careless assembly, installation or use of this product.

2Install this unit on a flat and stable place that can support sufficient

weight. If you install this unit in an unstable place, such as on a carpet or

a straw mat, place a board under the unit. If installed in a poor location,

your TV/speaker may tip over or fall off the stand, resulting in personal

injury.

3When you install this unit, take measures to prevent it from falling over

by attaching wire or the L bracket.

4Do not install the unit against a sliding door, a partition or other place that

is not sturdy enough.

5Be sure that the installation is performed by two or more people. When

moving the unit, lift it up from the base board and carry. If you lift it up

by other than the base board, it may damage this unit.

6Be sure to use all of the screws and/or mounting hardware indicated in the

install manual. Tighten screws securely in every location as directed.

7Do not lean on or place objects on the corner of your TV/speaker.

8Do not rattle or hit the unit.

9Do not make any alterations to parts or use any broken parts.

10Do not install in a humid or dusty place, or where your TV/speaker would

be subject to steam or oily smoke.

11Install this unit in a well-ventilated, cool, dry and clean place. For

minimum clearances for proper ventilation, refer to the owner’s manual

of your TV/speaker.

12Mount your TV/speaker properly. If not, your TV/speaker may tip over or

fall off the stand, resulting in personal injury.

13Do not use on a wet or waxed floor. If this product is used in such a

location, it may stick to the floor.

14Install in a place that does not get too hot. Installing it under direct

sunlight or close to a heater may result in bubbling, peeling or

discoloration of painted surfaces.

15Do not apply cellophane tape or other adhesive materials to painted

surfaces, as the paint may peel.

16Use a dry cloth to remove dust or dirt. If the unit is very dirty, wet the

cloth in a neutral detergent diluted with water and wring it out well before

wiping the unit. Note that if products like benzene, paint thinner or

household wax are used, they may cause the paint to fade and/or damage

the finish.

17Do not drop a sharp object on this unit, as damage may result.

18This install manual provides explanations of important precautions to

take to avoid any accidents, as well as how to assemble and install the

unit. During installation, also refer to the owner's manuals of your TV and

speaker, and attain a good understanding of them before proceeding

according to their directions.

19After reading, keep this manual in a safe place for future reference.

Compatible TV size: up to 52-inch, under 45kg

*Compliant with VESA Mounting Interface Standard and with the distance

between mounting holes described above.

The diameter of the screws should be up to 8mm (the diameter of the supplied

screws are 5mm, 6mm, 8mm).

Before installation, read the owner’s manual of your TV or measure

the distance of the mounting holes on the rear panel of your TV, and

check if your TV is possible to install. Note that even if the distance

of the mounting holes of your TV is the same as the distance

described above, there may be a case that you cannot install your TV

if there is a projection or input/output terminal in the way of the

bracket attachment area or if the bracket blocks the ventilation of the

TV.

This product is compatible with the following speaker models.

(As of October, 2009)

YSP-4000, YSP-5100/4100, YAS-81/71, YHT-S1400/S400

SAFETY PRECAUTION

COMPATIBLE TV

Compatible distance between mounting holes on the rear panel of the TV

(W × H)* unit = cm

20 × 2030 × 2030 × 3040 × 20

40 × 3040 × 4050 × 2060 × 40

COMPATIBLE SPEAKER

G

Integrated TV/Soundbar Pedestal

Socle intégré pour téléviseur et projecteur de son

YTS-T500

Install Manual

Manuel d’installation

Installationsanleitung

Installationsanvisningar

Printed in Malaysia WU17410-1

Manuale d’installazione

Manual de instalación

Installatiehandleiding

Руководство по установке
