Seite 1/11

Ver. 150806

To ensure safe and easy installation, please read

the following precautions

www.ZALMAN.com

User’s Manual

CNPS9900 Series

CNPS9900 Max

CNPS9900A LED / NT

Intel Socket LGA 2011 V3/2011/ 1366 / 1156 / 1155 / 1151 / 1150 / 775 CPUs

AMD Socket FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2 CPU&APUs

Intel Socket LGA 1366 / 1156 / 1155 / 1151 / 1150 / 775 CPUs

AMD Socket FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2 CPU&APUs

.COM

1. Precautions

2. Specications

1) Avoid inserting objects or hands into the fan while it is in operation to

prevent product damage and injuries.

2) Do not ingest the Thermal Grease, and avoid its contact with skin and

eyes. If contact is made with skin, wash off with water. If ingested or

irritation persists, seek medical attention.

3) To prevent possible injuries, gloves must be worn while handling this

product.

4) Excessive force exerted on the fan may cause damage to the fan and/

or system.

5) Use and keep product away from the reach of children and pets.

6) Check the components list and condition of the product before

installation. If any problem is found, contact the retailer to obtain a

replacement.

7) Zalman Tech Co., Ltd. is not responsible for any damages due to

overclocking.

8) Before transportation of the system, the cooler must be removed.

Zalman is not responsible for any damages that occur during the

transport of a system.

9) Enable PWM function in BIOS settings after installation.

10) Product design and specifications may be revised to improve quality

and performance.

Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due

to external causes, including but not limited to, improper use,

problems with electrical power, accident, neglect, alteration, repair,

improper installation, or improper testing.

Model

Spec.

CNPS9900A LED CNPS9900 NT

CNPS9900 MAX

(BLUE / RED)

Material Pure Copper Pure Copper, Black-Pearl Nickel Plated

Weight 730g 755g

Dimensions 94(L) X 131(W) X 152(H)mm

Heat Dissipation Area 5,402㎠

Fan

Bearing 2 Ball-Bearing Long Life Bearing

Quiet Mode

[w/Resister]

RPM 800~1300 rpm±10% 900~1500 rpm±10%

Noise Level 18~28.5 dBA±10% 18~27 dBA±10%

Normal Mode

[w/o Resister]

RPM 1000~2000 rpm±10% 900~1700 rpm±10%

Noise Level 19.5~38.0 dBA±10% 18~30 dBA±10%

Thermal Grease

[M-STG2]

capacity 3.5g

Temp.Range -40℃ ~ +150℃ (-40 ~+302℉)

.COM

3. Components

1) Common Components

Thermal Grease

[ZM-STG2]

Loading Block

Side Caps

Nuts

Double-sided Tape

Backplate

Resistor

Allen Wrench

(3/32")

User’s Manual

Cooler

Silver Bolts B (3mm)

(Socket LGA 1156/1155/

1151/1150/775/

AMD)

Silver Bolts A (4mm)

(Socket LGA 2011 V3/

2011 CNPS9900MAX Only)

Gold Bolts

(Socket LGA 1366)

AMD Clip

Intel Clip

2) Intel Components 3) AMD Components

CNPS9900 MAX : 2011 V3/2011/1366/1156

/1155/1151/1150/775

CNPS9900A LED / NT : 1366/1156/1155/1151/1150/775

Socket FM2/FM1/AM3+/AM3/AM2+/AM2
