Seite 1/32
MagnaPool
®
(all models)
Hydroxinators are compatible with pH Link and Dual Link modules
H0642200_REVC
INSTALLATION MANUAL
FOR YOUR SAFETY - This product must be installed and serviced by a licensed electrician in
accordance with the latest enforced version of AS/NZ 3000 and any other applicable local installation
codes. Before installing this product, read and follow all warning notices and instructions that
accompany this product. Failure to follow warning notices and instructions may result in property
damage, personal injury, or death. Improper installation and/or operation will void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which can cause serious
injury, property damage, or death.
WARNING
Page 3
Page 2
MagnaPool™ | Installation Manual
Refer to the following websites for information on warranty and service in your country
For Australia, NZ, Asia and Sth Pacific go to www.zodiac.com.au
Table of Contents
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAN FILTER)
PUMP MODEL HORSEPOWER
FILTER MODEL
CONTROL PANEL MODEL SERIAL NUMBER
NOTES:
EQUIPMENT INFORMATION RECORD
Section 1. Important Safety Instructions ....... 3
Section 2. System Overview ........................... 5
2.1 Contents ........................................................................ 5
2.2 Specifications ................................................................5
2.3 Dimensions....................................................................6
2.4 Materials and Tools .......................................................6
Section 3. Plumbing......................................... 7
Section 4. Install Controller ............................ 8
4.1 Mount the Bracket .........................................................8
4.2 Install temperature sensor .............................................8
4.3 Electrical Connections ...................................................8
Section 5. Install the pH Link or Dual Link
Module on the Controller ............ 10
5.1 Install the POD Kit ....................................................... 10
5.2 Drill the Pipe ................................................................ 10
5.3 Install the POD ............................................................10
5.4 Install the POD Cap..................................................... 11
5.5 Install and Calibrate
the Sensor(s) ............................................................... 11
5.6 Install the pH Down Intake and Injection lines.............12
5.7 Calibration Procedure..................................................12
Section 6. Prepare and Balance
the Pool ......................................... 13
6.1 Set up the Media Filter ................................................13
6.2 Fill and Balance the Pool.............................................13
6.3 Starting the System ..................................................... 14
6.4 First Two Weeks .......................................................... 14
6.5 Water Chemistry Table ................................................14
6.6 pH Regulation Principle ...............................................15
6.7 Stabilizer (Cyanuric Acid) ............................................16
Section 7. Operation ...................................... 16
7.1 User Interface Overview ..............................................16
7.2 Initial start-Up ..............................................................17
Section 8. Installing and Assigning
Equipment .................................... 18
8.1 Filter Pump .................................................................. 18
8.2 Aux/Lights....................................................................20
8.3 Heating ........................................................................ 22
Section 9. Calibration and Priming .............. 23
9.1 pH Sensor Calibration .................................................23
9.2 ORP Sensor Calibration .............................................23
9.3 Setpoint(s) ................................................................... 23
9.4 Prime and Test
the pH Dosing Pump ...................................................24
9.5 Programming/Timers ................................................... 24
9.6 Reversing ....................................................................26
9.7 Slave Mode .................................................................27
Section 10. Pairing and Connecting
to Wi-Fi ..........................................27
10.1 Wi-Fi Direct Mode ........................................................27
10.2 Invitation Code ............................................................27
10.3 Frequently Asked Wi-Fi Connection
Questions (FAQs) ........................................................28
Section 11. Help Menu ..................................... 28
Section 12. Inspecting and Cleaning the
Electrode....................................... 29
Section 13. Winterizing .................................... 29
13.1 Winterize the pH/ORP Sensors ................................... 29
13.2 Reopening the Pool .....................................................29
Section 14. Troubleshooting ........................... 30
