ENENEN

for choosing a quality product from 4smarts

Thank You

MONITOR LAMP

LIGHTBAR

1 Safety Instructions

• Use only in dry indoor environments.

• Do not immerse the device in water or other liquids.

• Do not open or attempt to repair the product yourself.

• Operate only with the included USB-C cable.

• Keep out of reach of children without supervision.

2 Technical Specifications

Model: 4smarts Monitor LightBar

Material: ABS, PC, aluminium alloy

Light source: LED

Brightness: approx. 400 lx

Colour temperature: 2800 K – 5500 K (cool, warm or mixed)

CRI (Colour Rendering Index): ≥ 90

Dimming: stepless (continuously adjustable)

LED lifetime: approx. 60,000 h

Compatibility: for monitors with a screen thickness of 8 – 20 mm

Power supply: USB-C (5 V / 1 A)

Power consumption: max. 5 W

Cable length: approx. 1.5 m

Operating temperature: –10 °C to +40 °C

Operating humidity: 10 % – 90 % (non-condensing)

Product size: 402 × 91 × 38 mm

Weight: approx. 252 g

3 Getting Started

1. Attach the ScreenBar with the clip to the top of your monitor.

2. Connect the included USB-C cable to a USB port on your PC, laptop or power adapter.

3. Press the control button to switch on the lamp.

4. Adjust brightness and color temperature as required.

4 Function Notes

(1) Power & Brightness Button

Use this button to switch the lamp on or off. Short presses adjust the brightness

smoothly and continuously.

(2) Color Temperature Button

Press and hold to toggle between the light modes: cool, warm or mixed. Perfect for

any working or gaming environment.

(3) Weighted Clip

The weighted clip keeps the lamp stable on your monitor – no screws or tools required.

(4) LED Lights

The energy-efficient LEDs provide uniform, flicker-free lighting with up to 400

lux brightness.

(5) USB-C Input

Power the lamp via the USB-C port by connecting it to your PC, laptop, or a

compatible charger.

5 Troubleshooting

• Light does not turn on → check USB port.

• Flickering light → try another USB port or power supply.

• Uneven lighting → reattach clip to monitor.

6 Maintenance and Care

• Clean only with a dry, soft cloth.

• Always disconnect the lamp from the power supply before cleaning.

• Do not use water or aggressive cleaning agents.

• Disconnect from power when transporting or not used for a longer period.

7 Warranty

4smarts GmbH accepts no liability or warranty for damages resulting from improper

installation, assembly, or misuse of the product or failure to observe the user manual

and/or safety instructions.

8 Environmental Protection

From the time of implementation of the European directives 2012/19/EU and

2006/66/EC into national law, the following applies:Electrical and electronic

devices as well as batteries must not be disposed of with household waste.

The consumer is legally obliged to return electrical and electronic devices as well as

batteries to designated public collection points or the point of sale at the end of their life.

Details are regulated by the respective national law.The symbol on the product, the user

manual, or the packaging indicates these regulations.

By recycling, material recovery, or other forms of disposal of old devices/batteries, you

make an important contribution to protecting our environment.

9 Service and Support

For defective products or issues during installation, please contact your retailer or

the 4smarts product support at https://www.4smarts.com/contact

Service Hotline

Monday – Friday: 9 AM – 5 PM

+49(0)821 20708444

Email: [email protected]

Hereby, 4smarts GmbH declares that this product complies with the essential safety

requirements and other relevant regulations. For more information on the Declaration

of Conformity, please visit https: //www.4smarts.com

10 Declaration of Conformity

1

2

3

4

5
