Seite 1/5
www.ACOPower.com
Power Your Green Life!
HY-PTK-100Exp
4120 Valley Blvd Walnut, CA 91789, USA
+1-626-737 1140
650
505mm
+
505
650
30
Twin Core Cable
In Red and Black
1000mm/2*2.5mm²
Twin Core Cable
in Red and Black
with MC4
3M Velco
M4*14mm Flat-Heat cross-Screw
(For the Installation of Controller)
-
+
www.ACOPower.com
Power Your Green Life!
4120 Valley Blvd Walnut, CA 91789, USA
+1-626-737 1140
User’s guide
After receiving the solar panel kit, please check if all accessories are included in the package and prepare to test your kit:
1. Locate a sunlit area clear from hanging branches or obstacles.
2. Unclip the two latches (2, Table 1) on the side of the unit and fold two panels outward. Extend the two support legs (4,
Table 1) to desired length and lock the stands in position. Set solar panel kit in the position facing the sun.
Tip: To obtain the maximum output power of solar modules, it is recommended to adjust the solar modules based on solar
trajectory.
How to test the solar panel
Method 1: Use a multimeter
Set your multi-meter to measure DC voltage and put the red probe on the red positive MC4 cable (14a, Table 1) and the
black probe on the black MC4 cable (14b, Table 1) and make sure the connections are secure. the open-circuit voltage
should be displayed on your multi-meter and it should be around 17.6V-23V. This is your solar panel’s voltage without
going through the charge controller.
If you’re not getting something within that range or close to those numbers, you should check and make sure the solar
panel is in direct sunlight and that the connections between the MC4 cables and the multi-meter is secure.
Specifications
100w solar panel
Type Module Size N.W
Specification
Max-
Power
Max-
Power
Voltage
Max-power
Current
Open-
Circuit
Voltage
Short-
circuit
Current
Module mm Kg W V A V A
2*50w
650*505*30
15
2*50 17.8 2*1.81 22.3 2*3.03
(25.6*19.9*1.2 in) (33.1 lb)
HY-PTK-100Exp
