Seite 1/3
Portable
Solar Generator
User Manual
Car Socket
AC Power Outputs x2
AC Output Switch
AC Power Indicator
DC Outputs x3
1.Get To Know Your Gear
3.Charging Your Generator
2. Tech Speci cation
4.Powering on and o
1
2
3
4
5
6
7
8
9
10
11
12
13
Main Power Button
USB 5V/2.4A Outputs x2
Type-C PD Output
LED Light Panel Switch
DC Input Port
Wireless Speaker
Wireless Speaker Working LED Indicator
Main Power LED Indicator
LED Light Panel
USB QC3.0 Output
Remaining Power Level LED Indicator
Wireless Speaker AUX-IN
Wireless Speaker Play Control Button
1
2
3
4
5
6
7
8
9
10
11
12
13
A
A:
14
15
16
17
14
15
16
17
18
18
B
B:
1. Long press the Power Button for 2 seconds until the green LED light
comes on.
2. When not in use, long press the Power Button for 2 seconds until the
green LED light turns off.
Please make sure the green light is on before using.The Solar Generator
will stay on even without any power drawing.Make sure you turn it off
when not in use to prevent the battery from draining.
515.04Wh (3.7V/139,200mAh)
462Wh (3.7V/124,800mAh)
Lithium-ion Cell
DC 19V/4.5A by Adapter
100-120V~/ 60Hz ( for Generator1 Version)
220-240V~/ 50Hz ( for Generator2 Version)
USB-A Outputs: 5V/2.4A x2
USB-A QC3.0 p1-x1 (5V/3A,9V/2A)
USB-C PD 60W x1
DC 9-12.6V/10A Cigarette Lighter Socket p1-x1
DC 9-12.6V, 5A Max Output p1-x3
AC Output Power: Rated Output Power: 500W
Inverter Waveform: Pure Sine Wave
5W
10W
Net Weight: 5.5Kg
Dimension: 290x155x190mm
Warranty: 12 months
Capacity:
Battery Type:
DC Input:
MPPT Solar Input:
AC Output:
DC Output:
LED Lighting Function
Wireless Speaker
14-25V by Solar Panel (Max 120W)
Option
Option
Total Share 10A Max
3OHDVHVZLWFKRZKHQQRWLQXVHWRVDYHWKHHQHUJ\
5. When the power inverter is not working as intended, the LED light will
be red.
1.Turn on main power.
2.Long press the button for 2 seconds to turn on speaker.You will hear
a power up sound and see a blue LED light.
PS-Speaker
:KHQLQSDLULQJPRGHWKHEOXHOLJKWZLOOEHȵDVKLQJ6HDUFKIRU
“PS-Speaker” in your Bluetooth settings and pair it with your cell phone.
- Long press to previous song
+ Long press to next song
+Short click increase volume
- Short click to descrease volume
2.Open the cover.
1.Turn on main power.
3.Plug into car socket.
4.Output voltage: 9-12.6V
5.Output current: 10A(max)
2.Plug in DC output port.
3.DC output voltage: 9-12.6V
4.DC output current: 5A max per port
2.Long press the far right button to turn on LED light panel on
half brightness mode.
4.Click again for SOS mode.
5.Click again for strobe mode.
ΖQDQ\PRGHORQJSUHVVVHFRQGVWRVZLWFKRWKHOLJKWSDQHO
You can also just press one more time in strobe mode.
4.
5.How to Use AC Output Port
6.USB Output
7.Speaker
9.DC 12V
8.Car Socket
10.LED light panel
Short press play/pause
/RQJSUHVVVWRWXUQRQR
speaker
3.Click the button again to be on max brightness mode.
1.Turn on main power.
1.Turn on main power.
1.Turn on main power.
2.Plug your device into a USB output socket.
1. Long press the Power Button for
2 seconds to turn on the Solar
Generator.
2. Flip the switch between the 2 AC
outlets to the ON position.
3. Plug your device into the AC
outlet.
