Seite 1/8

Rev. 3/14

User Instructions

American DJ - www.americandj.com - Jellydome Instruction Manual Page 2®

Unpacking: Thank you for purchasing the Jellydome by American DJ®.

Every Jellydome has been thoroughly tested and has been shipped in

perfect operating condition. Carefully check the shipping carton for

damage that may have occurred during shipping. If the carton appears

to be damaged, carefully inspect your xture for any damage and be

sure all equipment necessary to operate the unit has arrived intact. In

the event damage has been found or parts are missing, please contact

our toll free customer support number for further instructions. Please

do not return this unit to your dealer without contacting customer sup-

port rst.

Introduction: The Jellydome is a DMX intelligent, LED fixture. The

fixture has three different operating modes; sound active- mode, show

mode, or it can be controlled by a DMX controller. It can operate as a

stand alone fixture or in a Master/Slave configuration. This unit is suit-

able for theaters, studios, retail stores, and other similar locations. For

best results use fog or special effects smoke to enhance the beams

projections.

Customer Support: American DJ provides a toll free customer ®

support line, to provide help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 8:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: [email protected]

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Warning! This may cause severe eye damage. Avoid looking directly

into the light source at all times!

Jellydome General Information

Produktspezifikationen

Marke:	Adj
Kategorie:	Lichteffektmaschine
Modell:	Jellydome
Breite:	210 mm
Tiefe:	210 mm
Gewicht:	2000 g
Produkttyp:	Disco-Strahler
Produktfarbe:	Schwarz
Steuerung:	Tasten
Höhe:	179 mm
Energiequelle:	AC
Stromverbrauch (Standardbetrieb):	27 W
Anzahl:	1
Lampentyp:	LED
Eingangsspannung:	100 - 240 V
Anzahl Lampe(n):	34 Lampen
Leuchtmittellebensdauer (in Std.):	30000 h
Lichtfarbe:	Blue, Green, Red, White
Beleuchtungsarten:	DMX, Sound activated
Beleuchtungssteuerungsprotokolle:	DMX
Anzahl der DMX-Kanäle:	3 Kanäle
Strahlungswinkel:	138 °
XLR-Eingang:	Ja
Eingangsfrequenz:	50 - 60 Hz
Kugeldurchmesser:	- "
Lampenleistung:	10 W
Dimmbereich:	0 - 100 %
