ASMB-585 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 ASMB-585 Startup Manual
• 1 Driver CD (user’s manual is included)
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
http://www.adobe.com/downloads/ (Acrobat is a
trademark of Adobe)
ASMB-585 Intel LGA1151 Xeon E3-1200 v5 /Core i3/i5/i7
series Micro ATX Server Board with 4 x PCIe slots, 6 x
USB3.0, 4 x GbE ports
Startup Manual
Standard SBC Functions
• CPU: Intel LGA1151 Xeon E3-1200 v5 /Core i3/i5/i7
series processors
• BIOS: AMI 128 Mb SPI BIOS
• Chipset: Intel®
C236
• System memory: Dual Channel DDR4 ECC/Non-ECC
1600/1866/2133 MHz unbuffered DIMM, Max. 64 GB
Note: Due to the inherent limitations of PC architecture,
the system may not fully detect 32 GB RAM
when 64 GB RAM is installed.
• SATA3 Interface: 7 SATA3 6Gb/s ports to support Intel
Matrix Storage with software RAID 0, 1, 10 & 5. (for
Windows only)
• Serial ports: Six serial ports, only supports RS-232
• Keyboard/Mouse connector: Supports standard PS/2
keyboard and mouse via KMBS1 pin header
• Watchdog timer: 255 level timer intervals (sec)
• USB 3.0: Supports up to Six USB 3.0 ports. Four ports
are in rear I/O, and two ports are on-board pin header.
• USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)
Display Interface
• Chipset: CPU integrated Intel HD graphics controller
• Display Memory: 1 GB maximum shared memory with 2
GB and above system memory installed
• Resolution:
- Supports RGB up to 1920 x 1200 resolution @ 60 Hz
refresh rate
- Supports DVI up to 1920 x 1200 resolution@ 60 Hz
refresh rate
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1:Intel
®
I219LM; LAN2 ~ LAN4: Intel®
I201AT
Mechanical and Environmental
• Dimensions (L x W): 244 x 244 mm (9.6” x 9.6”)
• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb
• Power consumption: Max. load: +3.3 V @ 17.57 A, +5
V @ 20.5 A, +12 V @ 16.74 A, +12 V (8P) @ 23.27 A, +5
Vsb @ 2 A, -12 V @ 0.3 A
• Operating temperature: 0 ~ 60° C (Depends on CPU
speed and cooler solution)
• Weight: 0.5 kg (weight of board)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/applied-computing-
systems/
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/new_de-
fault.aspx
This manual is for the ASMB-585 series Rev. A1
Part No. 2001058511
Print in China
2nd Edition,
November 2015
