MIC-3810 Startup Manual 1

Before you begin installing your IPC, please make sure that

the following items have been shipped:

1. 1 x MIC-3810-A1D1

2. 2 x Screws M2.5*6LR/S D

3. 1 x Screws M2.5x4.5L 1/4R/S D

4. 1 x Display card panel cover(U)

If any of the above items are missing or damaged, contact

your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF le.

Acrobat Reader can be downloaded at:

www.adobe.com/Products/acrobat/readstep2.

html (Acrobat is a trademark of Adobe)

MIC-3810

3U CompactPCI

®

Serial PCIe Carrier Board

Startup Manual

Standard Functions

•Backplane Interface: PCIe Gen3 x8

•PCIe Connector: PCIe x16, backwards compatible PCIe

x1, PCIe x4, PCIe x8

•Card Size: maximum dimensions of 176 x 68.9 mm (6.9”

x 2.7” inches).

•Power: +12V, +5V standby: Power consumption depend-

ing on plugged module, supports up to 80W

Mechnical and Environment

•Dimensions (W x H x D): 160.00 x 100.00 mm (6.30” x

3.95”)

•Non-operating Temperature: -40 ~ 85 °C (-40 ~ 185 °F)

•Operating Temperature (depending on module): -40 ~

70 °C (-40 ~ 158 °F)

•Operating Humidity: 95% @ 40 °C, non-condensing

•Non-operating Humidity: 95% @ 60 °C, non-condensing

•Vibration (5~500 Hz): 2.0 Grms

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/epc

For technical support services, please visit our support

website at:

http://support.advantech.com

This manual is for the the MIC-3810-A1D1.

Part No. 2041381000

Printed in China

Edition 1

July 2022

Specications
