ITA-2231 Startup Manual 1

Before installing the board, please ensure that the following

items have been shipped:

1. 1 x ITA-2231 IPC

2. 1 x ITA-2231 Accessory Box

3. 1 x ITA-2231 Warranty Card

If any of the above items are missing or damaged, please

contact your distributor or sales representative immediately.

Note: Adobe Acrobat Reader is required to view PDF

les. Adobe Acrobat Reader can be downloaded at www.

adobe.com/Prodindex/acrobat/readstep2.html (Acrobat is a

trademark of Adobe).

ITA-2231 Intel® 6th Generation Core™ i Processor 2U

Fanless System with 3 ITA-EM Slots

Startup Manual

Standard Functions

•Chip & Chipset: Intel Core™ i7-6822EQ processor and

QM170 Chipset

•BIOS: AMI SPI 128 Mb

•Memory: Onboard 16GB DDR4-2133

•Display:

Intel HD530, frequency 350 MHz,

Shared system memory up to 512MB SDRAM

•Dual display mode:

Display resolution up to 1920 x 1200 @ 60 Hz,

1 x DVI-I + 1 x DVI-D

•Storage:

- 1 x 3.5”HDD or 2 x 2.5”HDD

- 1 x 2260 size M.2 (only supports SATA interface)

•Expansion slot:

- 3 x ITA-EM slot

- 1 x PCI104

- 1 x Mini PCIe slot

System Specifications

•Ethernet: 2 x 10/100/1000M Ethernet

•USB: 4 USB 3.0, 3 USB 2.0

•DVI: 1 x DVI-D, 1 x DVI-I

•Serial port: 2 DB9 ports, supports RS-232/422/485

•Audio: 1 Speaker Out (supports 4W Amp),1 Mic-in

•ITA-EM module (optional): ITA-EM modules can be

optionally inserted into three ITA-EM slots to make up to

24 additional LAN or COM ports for expansion needs.

Mechanical and Environment

•Dimensions (W x H x D): 427 x 88 x 325 mm

•Voltage input: AC 100-240 or DC 110V

•Working temperature:

- 0 -40 °C (32 ~ 104 °F , with HDD)

- 25 - 60 °C (-13 ~ 140 °F, with SSD)

•Weight:

- Single power: 7.7 kg

- Dual power: 8 kg

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.tw/support

This manual is for the ITA-2231 Series.

Part No. 2001223112

Printed in China

3rd Edition

April 2018
