PCE-5B06-00A1E Startup Manual 1

PCE-5B06-00A1E Backplane: 6-slot BP for 6 slot Chassis, 1 PICMIG 1.3, 4 PCIe

PCE-5B06-00A1E Backplane: 6-slot BP for 6 slot

Chassis, 1 PICMIG 1.3, 4 PCIe

Startup Manual

Before you begin installing your card, please make sure

that the following materials have been shipped:

If any PCE-5B06-00A1E of these items are missing or

damaged, contact your distributor or sales representative

immediately.

Standard Functions

•PICMIG 1.3 slots:

PCE-5B06-00 supports PCE-5xxx CPU boards

• PCIe slots:

PCE-5B06-00 supports one PCIe x 16 slot, four PCIe x 1

slot

•USB (2.0) support: Four USB 2.0 port pin headers

Mechanical and Environment

•Dimensions: 317.5 x 142.17 mm

•Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V

+5VSBY, +3.3VSBY

•Power requirements: Refer to the CPU Board, add-on

Card & Peripherals

•Operating temperature: 0 ~ 60° C

•Weight: 0.3 kg (weight of board)

Packing listSpecifications

• 2 Two Port USB Cablep/n: 1700002204

•PCE-5B06-00A1E User Manual

1st.ED

p/n: 200K5B0610

•M4*6*0.7 Round Screws (15 pcs)

p/n: 1939000410

• 2 years quality warranty card p/n: 2190000902

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for the PCE-5B06-00A1E series Rev. A1

Part No. 200K5B0610

Printed in China

1st Edition

Feb. 2007
