MIC-75M11 Startup Manual 1

Before you begin installing your card, please make sure

that the following items have been shipped:

1. MIC-75M11 Module p1-x1

P/N : MIC-75M11-00A1E

2. MIC-75M11 Startup Manual p1-x1 P/N :20015M1100

3. Warranty Card P/N: 2190000902

4. Card Clamp Pad x 4 P/N:1990024989T000

5. Wall-Mount BKT (Left) p1-x1 P/N:

1960070545N001

6. Wall-Mount BKT (Righ) p1-x1 P/N:

1960070543N001

If any of these items are missing or damaged, please

contact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF file.

Acrobat Reader can be downloaded at: get.

adobe.com/reader (Acrobat is a trademark of

Adobe)

MIC-75M11

PCIE/PCI Expansion Module for MIC-7 Series

Embedded System

Startup Manual

PCIe Slots

•One PCIex16 socket

Note 1: PCIEx16 power consumption supports to 35W.

Note 2: For MIC-73 series products (ATOM CPU), only

supports PCIEx4 or PCIEx1 signal.

32-bit PCI

•One 32 Bit/33Mhz PCI socket

Note 1: PCI socket suppots 15W power consumption.

Environment

•Operation Temperature:

-20 ~ 60° C with 0.7 m/sec air flow: with 1 x Industrial SSD

without PC expansion boards

0 ~ 45° C with 0.7 m/sec air flow: with 1 x 2.5” HDD

without PC expansion boards

•Storage Temperature: - 40 ~ 85° C (-40 ~185° F)

•Relative Humidity: 95% @ 40° C (non-condensing)

Mechanical

•Dimensions (H x W x D): 92 x 90 x 230 mm

Note 1: Please add FAN into i-module, when add-on

card total power consumption is over 45W.

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://support.advantech.com.tw/support/default.

aspx

This manual is for the MIC-75M11 Series Rev. A1.

Part No. 20015M1100

Printed in China

1st Edition

January 2016
