MIC-75S20 Startup Manual 1

Before you begin installing your card, please make sure

that the following items have been shipped:

1. MIC-75S20 Module p1-x1

P/N: MIC-75S20-00A1E

2. MIC-75S20 Startup Manual p1-x1 P/N: 20015S2000

3. Warranty Card P/N: 2190000902

4. Card Clamp Pad x 4 P/N:1990024989T000

5. Wall-Mount BKT (Left) p1-x1 P/N:

1960070545N001

6. Wall-Mount BKT (Righ) p1-x1 P/N:

1960070543N001

7. SATA cable x 2 P/N : 1700014518

8. SATA power cable p1-x2 P/N : 1700023566-02

9. HDD tray power cable p1-x1 P/N : 1700024985-01

If any of these items are missing or damaged, please

contact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF file.

Acrobat Reader can be downloaded at: get.

adobe.com/reader (Acrobat is a trademark of

Adobe)

MIC-75S20

PCIE Expansion Module for MIC-7 Series

Embedded System

Startup Manual

PCIe Slots

•One PCIex16 socket

Note 1: PCIEx16 power consumption supports 35W.

•One PCIex4 socket

Note 1: PCIEx4 supports 15W power consumption.

Note 2: MIC-75S20 does not support MIC-7300 series

systems.

•Storage: 2 x 2.5’ hot swappable HDD tray

Environment

•Operating Temperature:

-20 ~ 60 °C with 0.7 m/sec air flow: with 1 x Industrial SSD

without PC expansion boards

0 ~ 45 °C with 0.7 m/sec air flow: with 1 x 2.5” HDD

without PC expansion boards

•Storage Temperature: - 40 ~ 85 °C (-40 ~185 °F)

•Relative Humidity: 95% @ 40 °C (non-condensing)

Mechanical

•Dimensions (H x W x D): 92 x 90 x 230 mm

Note 1: Please add a fan onto the i-module, if add-on

card total power consumption is over 45W.

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://support.advantech.com.tw/support/default.

aspx

This manual is for the MIC-75S20 Series Rev. A1.

Part No. 20015S2000

Printed in China

1st Edition

February 2016
