PCE-4B12-03 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• PCE-4B12-03 Startup Manual 1st Ed. p/n: 20024B1200
• 2-year quality warranty card p/n: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Standard functions
• PICMG 1.3 slots: PCE-4B12-03 supports PICMG 1.3
half-size server grade SHB (PCE-4XXX series)
• PCIe slots: PCE-4B12-03 supports one PCIe p1-x8 slot, four
PCIe p1-x4 slot, three PCIe x1
• PCI slots: PCE-4B12-03 supports three PCI slots
Mechanical and Environment
• Dimensions: 315 x 185 mm
• Power supply voltage: +12 V, +5 V, -12 V, +3.3 V +5 VSB
• Power requirements: Refer to the CPU Board, add-on
card & peripherals
• Operating temperature: 0 ~ 60 °C
• Weight: 0.356 kg (weight of board)
PCE-4B12-03
Backplane: 12 Slot PICMG 1.3 Half-size BP for 14-
slot Rackmount Chassis, 1 x PCIe x8, 4 x PCIe x4,
3 x PCIex1, 3 x 32-bit/33MHz PCI
Startup Manual
Connectors
Label Function
SHBA1 ~ SHBB1 PICMG1.3 CPU board slot
PPCIE1, PPCIE3,
PPCIE5
PCIe p1-x1 slot
PPCIE2 PCIe p1-x8 slot
PPCIE4,
P1PCIE1-P1PCIE3
PCIe p1-x4 slot
EATXPWR1 ATX2.0 24-pin power connector
PWR1 Big 4 pin power connector
VOLT1 Alarm board power connector
ATX12V1
ATX 12V Auxiliary 4-pin power
connector
FAN1~FAN7 FAN connector
FANDEC1 FAN detector connector
SMBUS1, SMBUS2
SMBus connector for chasis
monitor
JFP1
Power and Reset button con-
nector
Jumpers
Label Function
PSON1 ATX/AT Mode Selection
JFAN_CTRL1 System Smart Fan Control
JGENSEL1 PCIe generation selection
connector
JCOMP1 Enable compatibility for
non-compliant Gen1 end point
Connectors Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com.tw/support
This manual is for the PCE-4B12-03 series.
Part No. 20024B1200
Printed in China
1st Edition
November 2014
Specications
Jumpers
EATXPWR1
Pin Name
1 3.3 V
2 3.3 V
3 GND
4 5 V
5 GND
6 5 V
7 GND
8 Power OK
9 5 V SB
10 12 V
11 12 V
12 3.3 V
13 3.3 V
14 -12 V
15 GND
16 PSON#
17 GND
18 GND
19 GND
20 -5 V
21 5 V
22 5 V
23 5 V
24 GND
PWR1
Pin Name
1 12 V
2 GND
3 GND
4 5 V
VOLT1
Pin Name
1 5 VSB
2 GND
3 GND
4 -5 V
5 5 V
6 3.3 V
7 -12 V
8 12 V
FAN1 ~ FAN7
Pin Name
1 GND
2 12 V
3 FANIO1~FANIO7
SMBUS1, SMBUS2
Pin Name
1 5 V
2 SMBCLK
3 SMBDAT
4 GND
ATX12V1
Pin Name
1 GND
2 GND
3 12 V
4 12 V
PWR1
Pin Name
1 12 V
2 GND
3 GND
4 5 V
\
Jumpers (cont.)
2 PCE-4B12-03 Startup Manual
Jumpers (cont.)
