Seite 1/7
PCE-5B05V-30B1E Startup Manual 1
Before you begin installing your card, please make sure
that the following items have been shipped:
• One 2-port USB cable p/n: 1700002204
• PCE-5B05V-30B1E startup manual
• M4*6*0.7 round screws (5 pcs) p/n: 1939000410
• Warranty Card p/n: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
PCE-5B05V-30B1E Backplane: 5-slot BP for 2U Chas-
sis, 1 x PICMIG 1.3, 1x PCIe, 3 x 64-bit PCI-X
Startup Manual
Standard Functions
• PICMIG 1.3 slots:
PCE-5B05V-30 supports PCE-5xxx CPU boards
• PCIe slots:
PCE-5B05V-30 supports one PCIe x16 slot
• 64-bit PCI-X:
Three 64 Bit / 100 MHz PCI-X slots
• USB (2.0) support:
Four Universal Serial Bus ports to backplane
Mechanical and Environment
• Dimensions: 80.01 x 325 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V
SBY, +3.3 V
• Power requirements: Refer to the CPU board, add-on
card and peripherals
• Operating temperature: 0 ~ 60° C
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/Network/
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B05V-30B1E series.
Part No. 200K5B0503 4th Edition
May 2016
2 PCE-5B05V-30B1E Startup Manual
Connectors & Jumpers
Connectors
Label Function
SHBA1 ~ SHBD1 PICMG1.3 CPU board slot
PPCIE1 PCIe x 8 Slot
PPCIE2 PCE-5B05V-30: PCIe x 8 slot
P1PCIX1 64-bit / 66 MHz PCI-X slot
P1PCIX2 64-bit / 66 MHz PCI-X slot
P1PCIX3 64-bit / 66 MHz PCI-X slot
EATXPWR1 ATX2.0 24-pin power connector
EATX12V1 ATX 12v auxiliary 8-pin power connector
ATX12V1 ATX 12 V 4-pin power connector
VOLT1 Alarm board / CMM power connector
FAN1 FAN connector (box header)
FAN2 FAN connector (box header)
FAN3 FAN connector (box header)
FAN4 FAN connector (box header)
FANDEC1 FAN speed detector connector
SMBUS1 SMBus connector for chassis monitor
SMBUS2 SMBus connector for chassis monitor
JFP1 Power and reset button connector
IPMB1 IPMB connector
USB12 Two USB port pin header
USB34 Two USB port pin header
Jumpers
Label Function
PSON1 ATX / AT mode selection
JP1VI01 P1PCIX1 and P1PCIX2 3.3V / 5V VIO
Selection
PCI-X jumper setting
Bus Rate/
Mode
JPCIXCAPA1 JSEL100A1 JM66ENA1
PCI 25MHz (1-2)GND (1-2)High (2-3)GND
PCI 33MHz (1-2)GND (2-3)GND (2-3)GND
PCI 50MHz (1-2)GND (1-2)High (1-2)High
PCI 66MHz (1-2)GND (2-3)GND (1-2)High
PCIX 50MHz (2-3)10K to
GND
(1-2)High X
PCIX 66MHz (2-3)10K to
GND
(2-3)GND X
PCIX 100MHz (open) (1-2)High X
PCIX 133MHz (open) (2-3)GND X
Note: *”X” means “don’t use this pin”
*”Open” means “doesn’t need a jumper”
P1PCIX1~3 PCI Bus rate indicator
Bus rate/Mode LED8 LED9 LED10 LED11
PCI 25MHz OFF OFF ON OFF
PCI 33MHz OFF OFF ON ON
PCI 50MHz OFF OFF OFF OFF
PCI 66MHz OFF OFF OFF ON
PCI 50MHz OFF ON X OFF
PCI 66MHz OFF ON X ON
PCI 100MHz ON ON X OFF
PCI 133MHz ON ON X ON
