PCE-5B18-0GA1 (PCE-7B19-0GA1) Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

•1 x 2-port USB Cable p/n: 1700002204

•PCE-5B18-0GA1 (PCE-7B19-0GA1)

•Startup Manual p/n: 20417B1900

•M4*6*0.7 Round Screws (15pcs) p/n: 1939000410

•2 Year Quality Warranty Card p/n: 2190000902

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

PCE-5B18-0GA1 (PCE-7B19-0GA1) Backplane: 19

(18)-slot BP for 20-slot Chassis, 1 x PICMIG 1.3,

2 x (1) PCIe, 16 x 32-bit/64-bit PCI

Startup Manual

Standard Functions

•PICMIG 1.3 slots:

PCE-7B19-0G supports PCE-7xxx CPU boards

PCE-5B18-0G supports PCE-5xxx CPU boards

•PCIe slots:

PCE-7B19-0G supports two PCIe p1-x8 slots

PCE-5B18-0G supports one PCIe x16 slot

•32-bit PCI slots:

Sixteen 32 bit/33 MHz, 64 bit/66MHz PCI slots

Bridge Chip: Diodes PI7C9X113SLFDE

•USB (2.0) ports:

Four Universal Serial Bus ports as pin headers

Mechanical and Environmental

•Dimensions: 327.66 x 417 mm

•Power supply voltage: +12 V, +5 V, -12 V, -5 V,

+3.3 V, +5 VSBY

•Power requirements: Refer to the CPU board, add-

on card & peripherals

•Operating temperature: 0 ~ 60°C

•Weight: 1.7 kg (weight of board)

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://support.advantech.com/

This manual is for the PCE-5B18-0GA1 (PCE-7B19-

0GA1) series.

Part No. 20417B1900

Printed in China

1st Edition

January 2025
