Seite 1/25

ACR-3088 PORTABLE

USER MANUAL

EN - ENGLISH

DESCRIPTION

1. ON/OFF/FM/AM

2. HOUR/TU-

3. MIN/TU+

4. SLEEP/SNOOZE

DIMMER HI/LOW

5. AL 1 / VOL-

6. AL 2 /VOL+

7. SET/PRE M+

8. LED DISPLAY

9. BATTERY COMPARTMENT

10. SPEAKER

11. AC POWER CORD

12. WIRE ANTENNA

CONNECTING THE DEVICE

PLUG

THE AC CORD INTO THE POWER OUTLET. WHEN ELECTRICAL POWER

HAS BEEN INTERRUPTED AND RESTORED, THE CLOCK DISPLAY WILL SHOW

THE TIME. MAKE SURE TO RESET BOTH THE CORRECT TIME AND ALARM

TIME FOR PROPER OPERATION.

TIME SETTING

ON TIME DISPLAY MODE, PRESS AND HOLD THE SET/PRE M+ (7), THEN THE

CLOCK DISPLAY WILL BLINK. PRESS THE MIN/TU+ (3) OR HOUR/TU- (2) TO

SET THE CLOCK DISPLAY TO THE CORRECT TIME. PRESS SET /PRE M+ (7)

AGAIN WHEN FINISHED THE SETTING, THE TIME DISPLAY WILL NOT BLINK.

IT IS 12-HOUR DISPLAY FORMAT, LED INDICATOR WILL LIGHT UP WHEN THE

DISPLAY TIME IS PM.

DISPLAY BRIGHTNESS

ON TIME DISPLAY MODE, USE THE DIMMER HI/LOW (4) TO ADJUST THE

DISPLAY BRIGHTNESS. SELECT FROM: LIGHT AND DARK.

RADIO OPERATION

1. UNCOIL THE WIRE ANTENNA (12).

2. PRESS ON/OFF (1) ONCE, IT WILL TURN ON THE RADIO.

3. PRESS FM/AM (1) TO SELECT FM OR AM RADIO.

4. WHEN THE RADIO IS TURN ON IN FM MODE, LED INDICATOR NEXT TO

“FM” WILL LIGHT UP. THE LED INDICATOR WILL OFF WHEN RADIO IS IN

AM MODE.

5. PRESS MIN/TU+ (3) OR HOUR / TU-(2) TO ADJUST YOUR DESI

RED

FREQUENCY.

6. PRESS AL 2/VOL + (6) TO INCREASE THE VOLUME, THE MAXIMUM LEVEL

UP TO LEVEL 16. PRESS AL 1/VOL-(5) TO DECREASE THE VOLUME, THE

MINIMUM LEVEL OF VOLUME IS LEVEL 0.

Note:

If the reception is too weak and there is interference on the received station, try to improve the reception

by altering the position and uncoiling or coiling the antenna.

MEMORY OPERATION

THE CLOCK RADIO CAN STORE 10FM PRESETS AND 10AM PRESETS.

1. ON RADIO PLAYING MODE, PRESS UP MIN/TU+ (3) OR HOUR / TU-(2) TO

CHOOSE YOUR DESIRED FREQUENCY.

2. PRESS SET/PRE M+ (7) FOR APPROX. 3 SECONDS, A PRESET NUMBER

WILL SHOW AND FLASH ON THE LED DISPLAY (8). THEN SHORT PRESS

HOUR/TU- (2) OR MIN/TU+ (3) TO SELECT YOUR DESIRED MEMOR

NUMBERS FROM P1 T

O P10.

3. SELECT A PRESET LOCATION WITH BUTTONS MIN/TU+ (3) OR HOUR/TU-

(2). PRESS THE SET/PRE M+ BUTTON ONE MORE. THE STATION IS

PRESET.

REPEAT THE ABOVE STEPS, YOU CAN STORE YOUR DESIRED STATIONS.

AFTER SETTING IS OK, PRESS SET/PRE M+ (7) TO SELECT YOUR PRESET

FREQUENCY TO ENJOY RADIO BROADCASTING.

ALARM FUNCTION

• SET THE CORRECT VOLUME AND THE STATION AHEAD OF THE TIME.

THE DEVICE SWITCHES ON WITH THE LAST SET VOLUME.

• WHEN THE ALARM TIME IS REACHED, A DOT FLASHES NEXT TO “

AL1

BUZZER” OR “AL1 RADIO” AND “AL2 BUZZER” OR “AL2 RADIO”.

SETTING

OF THE ALARM (IN STANDBY MODE)

YOU CAN SET TWO ALARM TIMES AS BELOW PROCEDURES:

1. PRESS THE AL1/VOL- BUTTON (5) FOR APPROX. 3 SECONDS.

THE

INDICATOR BEGINS TO FLASH.

2. SET

THE HOURS WITH THE HOUR/TU- BUTTON (2) AND THE MINUTES

WITH MIN/TU+ BUTTON (3).

3. TH

USE THE AL1/VOL- BUTTON TO SELECT HOW YOU WANT TO

BE WOKEN UP. SELECT FROM:

• BUZ

A BUZZER SOUNDS WHEN THE ALARM TIME IS REACHED. T

VOLUME OF THE BUZZER CANNOT BE ADJUSTED.

• LAST

HEARD RADIO FREQUENCY

AS SOON AS YOUR SET ALARM TIME IS SHOWN, THE RADI

SWITCHES ON. THE LAST TUNED FM STATION PLAYS AT THE LAST

SET

VOLUME.

4. AFTER YOU HAVE MADE THE SETTING, THE SELECTED ALARM TIM

FLASHES FOR CA. 3 SECONDS. THE ALARM TIME IS STORED. THEN

THE

CURRENT TIME IS DISPLAYED.

TO SET THE SECOND ALARM TIME, REPEAT THE ABOVE STEPS WITH THE

AL2/VOL+ BUTTON (6).

P. 1

P. 2

Note:

• In case of an activated alarm time, a dot will light up at “AL1 BUZZER / AL1 RADIO” and/or at “AL2

BUZZER / AL2 RADIO”.

• If you do not press a button within 4 seconds, the settings are accepted automatically.

• The alarm function ends automatically after approx. 60 minutes and the device switches off.

TURN OFF THE ALARM

TO TURN OFF THE ALARM UNTIL THE FOLLOWING DAY, PRESS ON/OFF

BUTTON.

ACTIVATING / DEACTIVATING THE ALARM TIME

IN TIME MODE, REPEATEDLY PRESS THE AL1/VOL- OR THE AL2/VOL+

BUTTON, UNTIL THE DOT ON THE DISPLAY NEXT TO THE ALARM TIME TEST

GOES OUT.

SLEEP FUNCTION

IF YOU WANT TO LISTENING THE RADIO WHILE FALL ASLEEP. YOU CAN

USE SLEEP FUNCTION BY SETTING THE SLEEP TIME.

WITH THE RADIO ON, PRESS THE SLEEP / SNOOZE BUTTON (4) TO ENTER

INTO SLEEP MODE, THE 90 No. SHOWS ON THE LED DISPLAY (8). IT STATES

90-MINUTES OF SLEEP TIME AND TO BE SETTED IN SEQUENCE 90-80-70-60-

50-40-30-20-10-OFF. PRESS THE SLEEP / SNOOZE BUTTON (4) TO CHOOSE

YOUR DESIRED SLEEP TIME, THE SLEEP TIMER WILL CHANGE BY 10

MINUTES EACH TIME YOU PRESS THE SLEEP BUTTON (4). THE UNIT WILL

STOP PLAYING WHEN THE TIMER COUNTDOWNS FROM THE PRESET SLEEP

TIME TO THE END AND THEN SWITCH OFF BY ITSELF.

SNOOZE FUNCTION

ON ALARM SOUND MODE, PRESS ON/OFF (1) TO STOP THE ALARM, THE

ALARM WILL NOT RESUME. BUT IF YOU PRESS THE SLEEP/SNOOZE

BUTTON (4) TO STOP THE ALARM, THE AL ICON OF THE LED DISPLAY (8) WILL

BLINK, AND THE ALARM WILL RESUME AFTER 9 MINUTES.

BATTERY BACKUP

THIS CLOCK HAS A BACKUP POWER SYSTEM TO ENSURE CONTINUOUS

OPERATION DURING POWER FAILURE. INSERT 2xAAA BATTERY AND THE

CLOCK MECHANISM WILL CONTINUE TO MAINTAIN THE CURRENT TIME

AND ALARM PROGRAM.

SPECIFICATION

POWER SUPPLY: AC 220-240V ~ 50Hz

POWER CONSUMPTION: 5W

BATTERY POWER RESERVE: 2x1.5V, AAA, R03 (BATTERIES NOT

INCLUDED)

FREQUENCY RANGE: FM: 87.5 ~ 108 MHz

AM: 522 ~ 1620 KHz

DRIPPING & VENTILATION WARNING

THE PRODUCT SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND

THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE

PLACED ON THE PRODUCT. THE NORMAL VENTILATION OF THE PRODUCT

SHALL NOT BE IMPEDED FOR INTENDED USE.

IMPORTANT SAFETY INSTRUCTIONS

Warning:

1. No naked flame sources, such as lighted candles, should be placed on the

apparatus.

2. Attention should be drawn to environmental aspects of battery disposal.

3. Do not install this equipment in a confined or building-in space such as a

book case or similar unit, and remain a well ventilation conditions.

The

ventilation should not be impeded by covering the ventilation openings with

items such as newspaper, table-cl

oths, curtains etc.

4. WARNING: Only use attachments/accessories specified or provided by the

manufacturer.

5. WA

RNING: Please refer the information on exterior rear enclosure for

electrical and safety information before installing or operating t

apparatus.

6. WA

RNING: To reduce the risk of fire or electric shock, do not expose this

apparatus to rain or moisture. The apparatus shall not be exposed t

dripping or splashing and that objects filled with liquids, such as vases, shall

not

be placed on apparatus.

7. WARNING: The battery (battery or batteries or battery pack) shall not be

exposed to excessive heat such as sunshine, fire or the like.

8. WARNING: Mains plug is used as disconnect device, the disconnect device

shall remain readily operable.

9. When not in use and during movement, please take care of the power cord

set. When put into use again, please make sure the power cord set bei

not damaged, if any damages found, please look for the service person to

replace the power cord set specified by the manufacturer or have the same

char

acteristics as the original one.

10. Use of the apparatus in moderate climates.

11. This equipment is a Class Ⅱ or double insulated electrical

appliance. It has been designed in such a way that it does not

require a safety connection to electrical earth.

DISPOSAL OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT

This symbol on the product or packaging means that the product should not be

treated as household waste. Do not throw garbage at the end of its life, but take it to

a collection center for recycling. In this way you will help to protect the environment

and be able to prevent any negative consequences that it would have on the

environment and human health. To find your nearest collection center:

- Contact local authorities;

- Access the website: www.mmediu.ro;

- Request additional information from the store where you purchased the product.

P. 3

P. 4

Produktspezifikationen

Marke:	Akai
Kategorie:	Armbanduhr
Modell:	ACR-3088
Display-Typ:	LED
Bildschirmdiagonale:	0.6 "
Eingebaute Lautsprecher:	Ja
Wecker:	Ja
Breite:	137 mm
Tiefe:	51 mm
Produktfarbe:	Schwarz
Akku-/Batterietyp:	AAA
Höhe:	72 mm
Energiequelle:	Wechselstrom/Batterie
Radiotyp:	Uhr
Tunertyp:	Digital
Unterstützte Bänder:	AM, FM
Digitales UKW-Radio:	87.5 - 108.5 MHz
Anzahl voreingestellter Stationen:	10
RMS-Leistung:	- W
AC Eingangsspannung:	220 - 240 V
AC Eingangsfrequenz:	50 Hz
Eingebautes Display:	Ja
Sleep-Timer:	Ja
Snooze Funktion:	Ja
Playback MP3:	Nein
Projektion:	Nein
Färbung:	Einfarbig
Lautstärkeregler:	Tasten
Antennentyp:	Intern
Verpackungsbreite:	150 mm
Verpackungstiefe:	70 mm
Verpackungshöhe:	105 mm
Stromverbrauch (Standardbetrieb):	5 W
Verpackungsart:	Box
Anzahl unterstützter Akkus/Batterien:	2
Integrierte Uhr:	Ja
Ein-/Ausschalter:	Ja
Akku-/Batteriespannung:	1.5 V
AM-Bandbereich:	522 - 1620 kHz
Alarm:	Ja
Hintergrundbeleuchtung:	Ja
Farbe der Hintergrundbeleuchtung:	Rot
PLL-Synthesizer:	Ja
Radio-Weckmodus:	Ja
