Seite 1/4
American DJ®
American DJ ®
4295 Charter Street
Los Angeles Ca. 90058
www.americandj.com
Unpacking: Thank you for purchasing the Fire Bowl™ by American
DJ . Every Fire Bowl™ has been thoroughly tested and has been ®
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the carton
appears to be damaged, carefully inspect your xture for any damage
and be sure all equipment necessary to operate the system has arrived
intact. In the case damage has been found or parts are missing, please
contact our toll free customer support number for further instructions.
Introduction: The Fire Bowl™ is ready to be hung or set on a
flat surface. The Fire Bowl™ produces a unique flame effect. The
simulated flame effect is further enhanced by the case design that
is designed to look like an ancient torch bowl. This unit may be
hung anywhere by the included hanging hardware, without the
typical danger of an open flame.
Customer Support: American DJ provides a toll free customer sup-®
port line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
your nearest American DJ dealer.®
Safety Issues: This unit may blow a fuse if the maximum allotted load
of 3 amps is reached. If the fuse needs replacement, always replace
the fuse with same exact type that was remove, unless otherwise
instructed by an authorized American DJ service technician. Use of a ®
different type fuse from that which is recommended may cause fire or
electric shock and will void the manufactures warranty.
Fire Bowl™ Introduction
© ®American DJ Supply - www.americandj.com - Fire Bowl™ Instruction Manual Page 2
Revised 5/03
User Instructions
• Be sure that the local power outlet match that of the required voltage
for your unit.
• Do not attempt to remove or break off the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short.
• Do not remove the fan cover under any conditions. There are no
user serviceable parts inside.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture.
• This unit is intended for indoor use only, use of this product outdoors
voids all warranties.
• During long periods of non use, disconnect the unitʼs main power.
• Always mount this unit in safe and stable matter.
• Power-Cord Protection - Power-supply cords should be routed
so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they exit from
the fixture.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer.
• The fixture should be serviced by qualified service personnel when:
A. The power cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The fixture does not appear to operate normally or exhibits a
marked change in performance.
Fire Bowl™ Safety Precautions
Unit Preparation:
Before beginning initial setup of your Fire Bowl,™ make sure there is
no evident damage caused during transportation. In the event that the
unitʼs housing or cable is damaged, do not plug the unit in and do not
attempt to use. Please contact customer support for assistance.
1. Remove all packing materials from the Fire Bowl.™
2. Place the Fire Bowl™ on a at level surface or suspend the unit
from the ceiling using the included hanging hardware.
3. Plug the power cord into a grounded electrical outlet with a match-
ing power supply.
4. There is no power switch. The unit should start immediatley after
being plugged in.
Lamps:
The positioning of the lamps is pre-set and does not require any type of
adjustment. Improperly positioned lamps will create deep spots of color
in the ame. Should the lamps need adjustment due shifting during
transit or after the replacement of a lamp, the lamps may be angled
slightly to overcome any heavy color wash. Should the lamps position-
ing become incorrectly, adjust them as follows:
1. To properly position the lamp the unit must be on. Use an insulated
screwdriver to make any adjustment to the lamps position.
2. The amber lamps should be angled to focused on the lower half of
the silk drape.
3. Position the blue lamp to shine directly in the center of silk drape.
4. All lamps will eventually fade or fail. Replacements lamps are
available from your dealer.
Silk Flame:
Your silk ame has been specially designed and hand cut from ne silk
to interact with the airow and lights to create the illusion of a ame.
Each silk drape is applied prior to shipment and should be in the correct
position. The silk drape has a life of approximately one month when
used continuously in a clean environment. Additional silk drapes may be
purchased through your dealer (part number Z-FLAMEBOWL/SILK).
Fire Bowl™ Set-Up/Operation
© ®American DJ Supply - www.americandj.com - Fire Bowl™ Instruction Manual Page 4© ®American DJ Supply - www.americandj.com - Fire Bowl™ Instruction Manual Page 3
Fire Bowl™ Halogen Lamp Warning
This fixture is fitted with halogen lamps which are highly susceptible
to damage if improperly handled. Never touch the lamps with your
bare fingers as the oil from your hands will shorten lamp life. Also,
never move the fixture until the lamps have had ample time to cool.
Remember, lamps are not covered under warranty conditions.
Fire Bowl™ Set-Up/Operation Cont.
Repositioning The Flame (Silk Drape):
You may wish to reposition the ame drape to customize the effect.
1. Move the ame drape along the ame attachment rail by sliding
the magnetic ends along the rail.
2. For best results, do not stretch out the ends of the silk drape as
tight as it can get along the bottom. For a more realistic effect
allow some play between the two ends of the silk drape, move the
magnets slightly away from the side of the casing to achieve a
more realistic ame effect.
3. For best results; experiment with the ame position. Slight changes
in the position of the silk drape can drastically change the effect.
© ®American DJ Supply - www.americandj.com - Fire Bowl™ Instruction Manual Page 6
© ®American DJ Supply - www.americandj.com - Fire Bowl™ Instruction Manual Page 5
Fire Bowl™ Silk Drape
If the silk drape becomes creased, you may iron the ame using a non-
drip iron on a low setting. Do not steam iron.
If the silk drape becomes frayed, you may use a sharp pair of scissors
to carefully cut the loose silk strands. The silk drapes may become
frayed after a period of four weeks.
Fire Bowl™ Warranty Registration
The Fire Bowl™ carries a 1 Year limited warranty. Please fill out the
enclosed warranty card to validate your purchase. All returned service
items whether under warranty or not, must be freight pre-paid and
accompany a return authorization (R.A.) number. If the unit is under
warranty you must provide a copy of your proof of purchase invoice.
Please contact American DJ customer support for a R.A. number.®
Fire Bowl™ Cleaning
Fixture Cleaning:
Due to fog residue, smoke, and dust cleaning should be carried out
periodically to optimize light output. Cleaning frequency depends on
the environment in which the fixture operates (I.e. smoke, fog residue,
dust, dew). In heavy club use we recommend cleaning on a monthly
basis. Periodic cleaning will ensure longevity, and crisp output. Always
be sure the unit is turned off and unplugged before performing any
cleaning procedures.
1. Use normal glass cleaner and a soft cloth to wipe down the outside
casing.
2. Use a brush to wipe down the fan grill.
3. Whip down the colored bulb covers with a damp cloth to remove
residue.
4. Always be sure to dry all parts completely before plugging the unit
back in.
Fire Bowl™ Lamp & Fuse Replacement
Caution: Always replace with the exact same type lamp and fuse,
unless otherwise specified by an authorized American DJ techni-®
cian. Replace with anything other than the specified part can damage
your unit and will void your manufactures warranty.
Warning: If after you have replaced the lamp or fuse and you con-
tinue to blow either one, STOP using the unit. Contact customer sup-
port for further instructions, you may have to return the unit for ser-
vicing. Continuing to use the unit may cause serious damage.
Fuse Replacement: Disconnect the unitʼs main power supply. Insert
a standard flat head screw driver in to the fuse holder housing located
on inner plate of the unit. Turn the screwdriver in counter-clockwise
direction to unlock the fuse holder. Remove the fuse holder to expose
the fuse. Remove the old fuse and discard it. Replace the fuse with
the same type. Insert the fuse holder back into itʼs housing and turn it
in clockwise direction to lock the holder back in to place.
Lamp Replacement: Caution! Never attempt to change the lamps
while the fixture is plugged in. Always disconnect the main power
and allow the unit ample time to cool before attempting to replace the
lamp.
1. Be sure to follow the proper procedures when handling halogen
lamps. Never touch the new lamp with your bare fingers.
2. Carefully pull the lamp out of the socket and discard it.
3. Replace the lamp with an exact match.
4. If necessary adjust the position of the lamps.
