© ® American DJ - www.americandj.com - Gobo Flash 4™ Instruction Manual Page 2
American DJ ®
4295 Charter Street
Los Angeles Ca. 90058
www.americandj.com
User Instructions
Introduction: Thank you for purchasing the Gobo Flash 4™ by
American DJ . The Gobo Flash 4™ is a packaged lighting system ®
(systems includes; 3 XLR cable, 4 Gobo Flash™ units). Everything you
need for a great portable lighting system is included in this one pack-
the master unit. The master unit is sound active and will run all pro-
grams through the built-in microphone in the master unit. This system
is great for mobile DJ’s, bands, and small clubs. For best results use
this system with a fog machine or other type of special effect smoke to
enhance the colorful beams.
Unpacking: Every Gobo Flash 4™ system has been thoroughly
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
the system have arrived intact. In the event damage has been found
number for further instructions. Please do not return the system to
your dealer without rst contacting customer support.
support line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.americandj.com for any com-
ments or suggestions. For service related issue please contact Ameri-
p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
not expose this system to rain or moisture.
contact American DJ.
Please recycle the shipping carton when ever possible.
Gobo Flash 4 Introduction
Rev. 12/02
Gobo Flash 4 Safety Precautions
© ® American DJ www.americandj.com Gobo Flash 4™ Instruction Manual Page 3
© ® American DJ www.americandj.com Gobo Flash 4™ Instruction Manual Page 4
Gobo Flash 4 Contents
Introduction................................................................................2
Unpacking..................................................................................2
Product Registration.................................................................3
Safety Precautions.......................................................................4
Controls & Functions................................................................5
Set-Up....................................................................................6
Operation..............................................................................7
Lamp Replacement...............................................................8
Cleaning................................................................................9
Warranty..............................................................................10
Specifications...........................................................................11
Gobo Flash 4 Product Registration
The Gobo Flash 4™ system carries a one year (365 days) limited war-
ranty. Please fill out the enclosed warranty card to validate your pur-
be freight pre-paid and accompany a return authorization (R.A.) num-
ber. The R.A. number must be clearly written on the outside of the
return package. A brief description of the problem as well as the R.A.
the shipping carton. If the unit is under warranty, you must provide a
copy of your proof of purchase invoice. You may obtain a R.A. num-
ber by contacting our customer support team on our toll free custom-
not displaying a R.A. number on the outside of the package will be
returned to the shipper.
Do not spill water or other liquids into or on to your unit.
Be sure that the local power outlet match that of the required volt-
age for your unit.
Do not attempt to operate this unit if the power cord has been frayed
or broken. Please route your power cord away from foot trafc.
Do not attempt to remove or break off the ground prong from the
electrical cord. This prong is used to reduce the risk of electrical
shock and re in the event of an internal short.
Disconnect from main power before making any type of connection.
Do not remove the rear cover under any conditions. There are no
user serviceable parts inside.
Never plug this unit in to a dimmer pack
Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
Do not attempt to operate this unit if it becomes damaged in any way.
Never operate this unit when it’s front cover is removed.
To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
During long periods of non-use, disconnect the unit’s main power.
Always mount this unit in safe and stable matter.
Power-Cord Protection - Power-supply cords should be route so
they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords a plugs,
convenience receptacles, and the point where they exit from the
xture.
• Cleaning -The xture should be cleaned only as recommended by
the manufacturer.
Heat -The xture should be situated away from heat sources such
as radiators, heat registers, stoves, or other appliances (including
ampliers) that produce heat.
The xture should be serviced by qualied service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The xture does not appear to operate normally or exhibits a
marked change in performance.
Gobo Flash 4 Unpacking
• Blackout Controller Included
• Built-in Programs
• Master/Slave units via XLR Cables
• Sound Active
• Fan Cooled
• Built-In Hanging Bracket
• Easy Access Lamp Replacement Door
• Lamp: LL-EFP 12v/100w
• Optional “Special Occasion” Gobo Wheel Available
Figure 2
© ®American DJ - www.americandj.com - Gobo Flash 4™ Instruction Manual Page 5 American DJ - www.americandj.com - Gobo Flash 4™ Instruction Manual Page 6© ®
Power Supply: Before plugging your units in, be sure the source
voltage in your area matches the required voltage for your American
DJ Gobo Flash 4™ units. The American DJ Gobo Flash 4® ®
system is
available in a 120v and 220v version. Due to variations in line voltage
a matching power supply before attempting to operate.
Data Cable Requirements: Your units require a standard 3-pin
XLR microphone cables for data input and data output (Figure 1).
The system includes three cables. If you require cables of different or
extended lengths, you may uses any standard
microphone cable or construct your own. If you
are constructing your own cables, be sure to
use standard two conductor shielded cable (this
cable may be purchased at almost all pro sound
and lighting stores). Your cables should be made
with a male and female XLR connector on either
end of the cable. Also remember that DMX cable
must be daisy chained and can not be split.
Notice: Be sure to follow gure three when making your own cables.
cable’s shield conductor to the ground lug or allow the shield conduc-
tor to come in contact with the XLR’s outer casing. Grounding the
shield could cause a short circuit and erratic behavior.
Figure 1
DMX512 IN
3-PIN XLR
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 3
Gobo Flash 4 Set Up
1 Ground
1 Ground
XLR Male Socket
XLR Pin Conguration
3 Hot
2 Cold
2 Cold
3 Hot
XLR Female Socket
Pin 3 = Data True (positive)
Pin 2 = Data Compliment (negative)
Pin 1 = Shield
1. Microphone - This microphone receives external low frequencies
to trigger the unit. Tapping on the unit and high pitched sounds
may not trigger the unit.
2. Cooling Fan - The this high speed fan is designed to cool the
unit during normal operation. Never block the cooling vents. Keep
the vents clean at all times.
3. XLR Slave Outputs - These signal outlet are used to send a con-
trol signal to any slave unit directly connect to any of these jacks.
Use the included XLR cables to link units together.
4. Remote Control Input - Do not attempt to connect an audio
signal to this jack, this will damage the unit! This jack is for
use with the blackout controller only. Connecting an audio signal
this jack, this will damage the PC board and void your manufac-
tures warranty!
5. Fuse Holder - This housing store the protective fuse. Always
replace with an exact match. For fuse replacement procedures
see page 9.
6. Power Cord - Connect only to a matching power outlet. Never
use this xture if the ground prong has been removed or broken
off.
Gobo Flash 4 Controls and Functions
4
5
3
1
6
2
Master Unit
