Q-D5 MKII
™
Professional Preamp Mixer
American Audio
6122 S. Eastern Ave.
Los Angeles Ca. 90040
www.AmericanAudio.us
Rev. 4/08
Introduction:
Congratulations and thank you for purchasing the American Audio Q-D5 MKII™ mixer. This mixer is ®
a representation of American Audio’s continuing commitment to produce the best and highest quality
audio products possible at an affordable price. The Q-D5 MKII™ comes with a 1 year limited warranty!
Please read and understand this manual completely before attempting to operate your new mixer. This
booklet contains important information concerning the proper and safe operation of your new mixer.
Customer Support:
American Audio provides a toll free customer support line, to provide set up help and to answer any ®
question should you encounter problems during your initial set up or operation. You may also visit us
on the web at www.AmericanAudio.us for any comments or suggestions. Service Hours are Monday
through Friday 9:00 a.m. to 5:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Caution! There are no user serviceable parts inside this mixer. Do not attempt any repairs yourself,
doing so will void your manufactures warranty. In the unlikely event your mixer may require service,
please contact American Audio customer support.®
Do not discard the packing carton in the trash. Please recycle when ever possible.
Q-D5 MKII™ Introduction
Q-D5 MKII™ Unpacking
Every Q-D5 MKII™ has been thoroughly tested and has been shipped in perfect operating condition.
Carefully check the shipping carton for damage that may have occurred during shipping. If the carton
appears to be damaged, carefully inspect your mixer for any damage and be sure all equipment nec-
essary to operate the mixer has arrived intact. In case damage has been found or parts are missing,
please contact our toll free customer support number for further instructions, please do not return the
mixer to your dealer.
© ®American Audio - www.AmericanAudio.us - Q-D5 MKII™ Instruction Manual Page 2
Please make any connections before you plug the mixer in. Be sure the Power switch is in the OFF
position before connecting other devices to the mixer. All fader and volume controls should be set to
0 or minimum position, before the device is switched on. If the device has been exposed to drastic
temperature uctuation (e.g. after transportation), do not switch on the mixer immediately. The arising
condensation of water might damage your device. Leave the device switched off until it has reached
room temperature.
Operating Determinations:
• When installing this mixer, please make sure that the device is not exposed to extreme heat,
moisture or dust!
• There should not be any cables lying around. Doing so endangers you as well as others.
• Do not operate the mixer in extremely hot (more than 30° / 100°F) or extremely cold (less than
5°C/ 40°F) surroundings.
• Keep the unit out of direct sunlight and away from heaters.
• Operate the mixer only after becoming familiar with its functions. Do not permit operation by
persons not qualied for operating the mixer. Most damages are the result of unprofessional
operation!
Q-D5 MKII™ Set-Up Precautions
• For adult use only - Keep out of the reach of children.
• Be sure that the local power outlet match that of the required voltage of the unit.
• Disconnect from main power before making any type of connection.
• Do not attempt any service. There are no user serviceable parts inside.
• Never plug this mixer in to a dimmer pack
• Always be sure to mount this mixer in an area that will allow proper ventilation.
• Do not attempt to operate this mixer, if it becomes damaged in any way.
• Never operate this mixer when it’s covers are removed
• To reduce the risk of electrical shock or re, do not expose this mixer rain or moisture
• This mixer is intended for indoor use only, use of this product outdoors voids all warranties.
• During long periods of non-use, disconnect the mixer’s main power.
• Always mount this mixer in safe and stable matter.
• Power Cord Protection - Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying particular attention to cords
at plugs, convenience receptacles, and the point where they exit from the mixer.
• Cleaning -The mixer should be cleaned only as recommended by the manufacturer.
• Heat -The mixer should be situated away from heat sources such as radiators, heat registers,
stoves, or other mixers (including amplifiers) that produce heat.
• Be sure to save the packing carton in case you may ever have to return the mixer for service.
• Read all documentation before attempting to operate your new mixer. Please save all your docu-
mentation for future reference.
• Do not spill water or other liquids in to or on to your mixer.
• Do not attempt to operate this mixer if the power cord has been frayed or broken. Please route
your power cord out of the way of foot trafc .
• Always have the front gain controls set to their lowest level during initial power-up to prevent
speaker damage.
• The mixer should be serviced by qualified service personnel when:
A. Objects have fallen, or liquid has been spilled into the mixer.
B. The mixer has been exposed to rain or water.
C. The mixer does not appear to operate normally or exhibits a marked change in
performance.
Q-D5 MKII™ Safety Precautions
Q-D5 MKII™ Main Features
• Optical Fader for Q-Start Control
• Adjustable Crossfader Curve - for crabbing
• Single Voltage or Dual Voltage
• 2 Phono/2 Aux, 2 Line Inputs
• Fader “Q” Start
• Q-Start Compatible (for use with compatible
American Audio CD Players )
• -30dB Rotary Kills for Treble, Bass and
Mids on both channels
• 100% Push Button Kills
• High output to headphones
• Replacable/Adjustable Transformer Switches
• Adjustable Channel Fader Curve
© ®American Audio - www.AmericanAudio.us - Q-D5 MKII™ Instruction Manual Page 3
• Soft-touch rubber knobs for better control
• Extremely clean signal to noise ratio
• Light Control Signal Output Jack
• Talk Over Button - Reduces channel output
gain by 15dB +/- 2 dB
• Dual Function Stereo LED Level Indicator -
Indicated Master and PFL (Pre Fader Level)
Signal Levels
• Split Cue Monitoring
• Cue Mixing
• Separate gain control for each channel
• Hot Swap Crossfader
• Separate Mic EQ Section
