Seite 1/10
AtlasIED.com
TELEPHONE: (800) 876-3333
SUPPORT@ATLASIED.COM
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
OWNER’S MANUAL
AC POWER DISTRIBUTION & SURGE SUPPRESSOR UNIT
AP-S20
OWNER’S MANUAL
AC POWER DISTRIBUTION & SURGE SUPPRESSOR UNIT
AP-S20
P R O D U C T S U M M A RY
The AtlasIED AP-S20 AC Power Distribution & Surge Suppressor Unit
has been designed to meet most installation requirements for AC power
distribution and equipment power protection.
The AP-S20 features noise ltering for unwanted Radio Frequency
Interference (RFI) that is commonly introduced into AC lines by nearby radio
transmitters or wireless products. The benet of these lters can be seen
on video products or audibly by reducing static pops and external signal
interference in sound reinforcement systems.
Unstable AC Mains voltage is one of the main reasons for equipment failure.
The amount of energy that can be injected into the power system can be
immense with voltages reaching 6kV or current peaks of 3000A. These
spikes are very fast and usually only last for a very short period of time. The
AP-S20’s circuitry is very fast and can suppress unwanted energy within a
nanosecond response and sustain the suppression up to 2 milliseconds,
thus ensuring virtually trouble-free protection. If the suppression circuitry is
damaged, the AC Protect LED will turn off to indicate a fault has occurred.
The AP-S20 offers power management control, noise ltering, and protection
against abnormal voltages, spikes, and surges, making it the most compact,
effective power management protection system on the market today.
K E Y F E AT U R E S
• 9 Total Outlets
• 7 Rear Panel Switched Outlets
• 1 Rear Panel Unswitched Outlet
• 1 Front Panel Unswitched Convenience Outlet
• 12 gauge 9' (2.74m) Cord
• RFI Noise Filtering to Reduce Radio Frequency Interference
• Circuit Breaker Protection @ 20A
• Voltage Protection Rating
• Clamping Voltage L-N: 400, L-G: 500, N-G: 400 / 3kA, 8/20μs
• Max. Spike Clamping Voltage 6kV, 1.2/50μs
• AC Protect Active Indicator
A U D I O A PP L I C AT I O N S
The AP-S20 was designed to be flexible with features that allow it to be used
in a variety of applications. The AP-S20 can be used solely for protection
against voltage surges or for AC distribution. If fuzzy video or frequent
static pops occur, the AC power conditioning may eliminate or reduce those
inconveniences. The following are just a few examples of applications where
the AP-S20 can be used:
• Restaurants
• Houses of Worship
• Schools
• Home Theaters
• Ofce Buildings
• Sports Bars
AtlasIED.com
TELEPHONE: (800) 876-3333
SUPPORT@ATLASIED.COM
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
AtlasIED.com
TELEPHONE: (800) 876-3333
SUPPORT@ATLASIED.COM
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
OWNER’S MANUAL
AC POWER DISTRIBUTION & SURGE SUPPRESSOR UNIT
AP-S20
TA B L E O F C O N T E N TS
INTRODUCTION
Product Summary ...................................................................................................2
Key Features.............................................................................................................2
Audio Applications 2 ..................................................................................................
SAFETY
Important Safety Instructions ..............................................................................4
PRODUCT
Front Panel Description..........................................................................................6
Rear Panel Description 6 ...........................................................................................
Installation ................................................................................................................7
Specications ...........................................................................................................7
Dimensional Drawings 9 ...........................................................................................
Warranty ..................................................................................................................10
