INSTALLATION INSTRUCTIONS

ATLAS SOUND PD-30(T)(-16),

PD-5V(H)(T),PD60A(T)

GENERAL DESCRIPTION

• High efficiency compression drivers with various power levels available

• Environment resistant construction for indoor/outdoor use

• Various horn types available for different coverage patterns and SPL’s

• Field replaceable diaphragms

PD-30(T)(-16)

Field connections are made to the 2 screw terminals located under the clear cover plate. Terminal 2 is positive with respect

to terminal 1. For the transformer equipped models, a screwdriver adjustable tap selector is also located beneath the

cover plate. Set the tap to the desired power level by lining up the screwdriver slot with the correct tap position. Do

not use

positions 6 or 7 (PD-30T) for a 70.7V line. It is recommended that the proper high pass filter be installed to limit low

frequency reproduction and to prolong diaphragm life. Low frequency cut off is a parameter of the horn attached

to this driver. Check with Atlas Sound for recommendations. See Capacitor Selection Chart for the proper value on

this document.

PD5VH(T)

Field connections for the

nontransformer version are located on the outside of the sound chamber and are marked “1”

and “2”. Pin 2 is positive with respect to pin 1.

For the transformer equipped version, field connections are made to the screw terminals located on the rear of the driver

assembly, beneath the clear protective cover. On this model, connect the common of your speaker line to the terminal

labeled “C”, the positive of your speaker line to the appropriate tap terminal.

It is recommended that the proper high pass filter be installed to limit low frequency reproduction and to prolong

diaphragm life. Low frequency cut off is a parameter of the horn attached to this driver. Check with Atlas Sound

for recommendations. See Capacitor Selection Chart for the proper value on this document

.

SPECIFICATIONS

MODELPOWER

RATING

PLANE WAVE

FREQ. RESPONSE

LOW FREQ. LIMIT

@ FULL POWER

SOUND

LEVEL˚

IMPEDANCEPOWER

TAPS

VOICE

COIL

DIMENSIONSWEIGHT

PD-5VH

40W110 - 4,100 Hz

(±5DB)

250Hz110.7 (AVG)

110 - 4,200 Hz (±5db)

16 (Nom.)–2”

(5CM)

5 1/8” H x 6

3/8” W (17.5cm

x 16.2cm)

4.10 lbs.

(1.9Kgs.)

PD-5VT40W190 - 4,200 Hz

(±5db)

300 Hz111.2 (avg)

190 - 4,200 Hz (±5dB)

2K, 1K, 500,

250, 125, 16

70.7V

@ -

2.5, 5, 10,

20, 40

6 7/8” H x

6 3/8” W

7 lbs.

(3.2Kgs)

SPECIFICATIONS

MODEL

POWER

RATING

PLANE WAVE

FREQ. RESPONSE

LOW FREQ. LIMIT

@ FULL POWER

SOUND

LEVEL˚

IMPEDANCEPOWER

TAPS

VOICE

COIL

DIMENSIONSWEIGHT

PD-30

30W

300 - 3,900 Hz

(±5dB)

500Hz

113.6 (avg) 300 -

3,900 Hz (±5dB)

8 (Nom.)–

1.5”

(3.2cm)

4.5” H x 4.5”

Dia. (11.4cm x

11.4cm)

3 lbs.

(1.45Kgs.)

PD-30-16

16 (Nom.)

_

4.75 lbs.

(2.1Kgs)

PD-30T45, 89, 167,

333, 666,

1300, 2500

70.7V@ -

1.8, 3.7,

7.5, 15, 30
