MBK62xA installation manual - V1 1
Installation manual
MBK62xA
The MBK62xA is a dedicated steel mounting bracket designed specifically for the AUDAC ARCHI series architectural
subwoofers, enabling secure and discreet installation on walls or ceilings. With its durable black finish and all necessary
mounting hardware included, the MBK62xA offers both reliability and ease of use. A smart sliding slot mechanism allows
the subwoofer to glide smoothly into place for easy and secure installation, whether mounted horizontally or vertically.
Rubber washers help minimize vibrations and protect mounting surfaces, while an integrated drop safety wire adds an
extra layer of security against accidental falls.
Included hardware:
MBK621A
(ARCHI10)
MBK622A
(ARCH10X)
MBK623A
(ARCHI210)
Mounting bracket*
*The image is for illustrative
purposes only, since it will
differ from the various
models.
1 piece 1 piece 1 piece
Silentblock washer and
rubber
4 pieces 4 pieces 4 pieces
Metal washer 4 pieces 4 pieces 4 pieces
M8x45 bolt
4 pieces 4 pieces 4 pieces
Drop safety wire with
buttonhead screw and
spring washer
1 piece
(M8 buttonhead
screw)
1 piece
(M10 buttonhead screw)
1 piece
(M8 buttonhead
screw)
Installation:
Step 1:
Remove the rubber feet from bottom of the cabinet or countersunk bolts from
rear of the cabinet, depending on whether you plan to mount it from the bottom
or the rear.
Insert the M8 bolts through Silentblock washer, then through the Silentblock
rubber and the metal washer.
Screw them into the four threaded holes at the corners.
The silentblock rubber is used to reduce vibrations and protect the bracket’s
mounting surfaces.
M8x45 Bolt
Silentblock
washer
Silentblock
rubber
Metal
washer
Step 2:
Install the drop safety wire to the
designated point using an M8 or
M10 buttonhead screw and spring
washer based on the model.
Secure the other end of the wire to
a different mounting point on the
wall or another structure that is
separate from the main suspension
surface.
Step 3:
Install the mounting bracket vertically or horizontally to the designated point on the
wall.
Insert the Silentblock into the slots in the mounting bracket and slide to secure.
Step 4:
Secure the speaker to the bracket by tightening the 4 lock screws against the
Silentblocks.
