AT33MONO

AT33MONO

Elliptical 1/2 inch Standard Mount Cartridge

The AT33Mono is made specifically for use on mono systems. It has a

horizontal coil, and so in principle only generates electricity horizontally.

The AT33Mono produces sound to a very high quality because it does not

easily pick up unnecessary strain components from distorted or scratched

records, producing audio that you couldn't possibly get from a stereo cartridge.

The AT33Mono also has appropriate compliance in the vertical direction, so will

not cause damage to stereo records.

Enjoy those well-known classic mono records of yesteryear with the

AT33Mono.

• Mono cartridge compatible with stereo playback systems.

• Elliptical stylus chip and hard duralumin cantilever.

• 10middle impedance specification.Ω

• PCOCC coil prevents crystal gain boundary formation (in transmission

direction).

• Strong body stabilized by a rigid body set-up.

• "Hanenite" anti-vibration rubber eliminates unnecessary vibrations.

• High-quality sound / Brass fastening screw.

*This model is not compatible with SP records.

RRP ex VAT365,00 €

RRP inc. VAT£389.00

Ean code: T4961310098964

Specifications*:

Type: MC-type

Playback frequency range: 20-20,000Hz

Output voltage: 0.35mV (1kHz and 5cm/sec. horizontal signal)

Horizontal/vertical output ratio: 30dB (1kHz)

Output balance:1.0dB (1kHz)

Stylus pressure: 2.3-2.7g (2.5g standard)

Coil impedance:10Ω1kHz

DC resistance: 10Ω

Load resistance:More than 100Ω(when head amp connected)

Coil impedance:28µH (1kHz)

Static compliance: 20×10－6cm/dyne

Dynamic compliance:6×10－6cm/dyne (100Hz)

Needle shape: Round needle (0.65mil)

Cantilever: Duralumin pipe

Vertical tracking angle:23°

Dimensions:H16×W16.6×D26.5mm

Weight: 6.9g

Accessories:Non-magnetic screwdriver x1, Washers x2, Protector x1,

Cartridge fastening screw 13mm×2, 19mm×2, Nut x2,

Brush x1, PCOCC lead set x1

*Specifications are subject to change without notice.

PCOCC = Pure Copper by Ohno Continuous Casting process
