Seite 1/2
U857R / U857RL
CARDIOID CONDENSER ADAPTER-MOUNT
GOOSENECK MICROPHONE
- Designed for high-quality sound
reinforcement, professional record-
ing and broadcasting.
- Superior off-axis rejection for maxi-
mum gain before feedback.
- UniGuard™ RFI-shielding technol-
ogy offers outstanding rejection of
radio frequency interference (RFI).
- Easy-to-adjust, rugged, small-
dimeter, alternating gooseneck with
virtually no “memory” permits quick
positioning into desired shape.
- UniSteep
®
lter provides a steep
low-frequency attenuation to im-
prove sound pickup without affect-
ing voice quality.
- Accepts interchangeable elements
to permit angle of acceptance from
90° to 360°.
- Two-stage foam windscreen yields
dramatically improved resistance to
P-pops and other breath blasts.
- Direct mounts to any "-27 stand, ⅝
or to included threaded mounting
ange.
The U857R stands 305mm from the table or podium, it is also
available in a 421mm version as U857RL. The two models are
identical in all other respects.
The microphone requires 11V to 52V DC phantom power for
operation.
Output from the power module's XLRM-type connector is low
impedance (Lo-Z) balanced. The signal appears across Pins
2 and 3; Pin 1 is ground (shield). Output phase is "Pin 2 hot" -
positive acoustic pressure produces positive voltage at Pin 2.
At integral 80 Hz high-pass UniSteep
®
filter provides easy
switching from a at frequency response to a low-end roll-off.
The roll-off position reduces the microphone's sensitivity to
popping in close vocal use. It also reduces the pickup of low-
frequency ambient noise (such as trafc, air-handling systems,
etc.), room reverberation and mechanically coupled vibrations.
The microphone features a 3m permanently attached miniature
cable. It connects to provided AT8538 power module via a spe-
cial TA3F-type connector designed to optimize RFI immunity.
Avoid leaving the microphone in the open sun or in areas where
temperatures exceed 43°C for extended periods. Extremely
high humidity should also be avoided.
SPECIFICATIONS
ELEMENT
POLAR PATTERN
FREQUENCY RESPONSE
LOW FREQUENCY ROLL-OFF
OPEN CIRCUIT SENSITIVITY
IMPEDANCE
MAXIMUM INPUT SOUND LEVEL
DYNAMIC RANGE (TYPICAL)
SIGNAL-TO-NOISE RATIO
PHANTOM POWER REQUIREMENTS
SWITCH
WEIGHT U857R
U857RL
POWER MODULE
DIMENSIONS U857R
U857RL
BOTH
POWER MODULE
OUTPUT CONNECTOR
CABLE
OPTIONAL INTERCHANGEABLE
ELEMENTS
ACCESSORIES FURNISHED
Fixed-charge back plate
permanently polarized condenser
Cardioid
30-20,000 Hz
80 Hz, 18 dB/octave
-39 dB (11.2 mV) re 1V at 1 Pa
250 ohms
139 dB SPL, 1 kHz at 1% T.H.D.
115 dB, 1 kHz at Max SPL
70 dB, 1 kHz at 1 Pa
11-52V DC, 2 mA typical
Flat, roll-off
124 g
131 g
81 g
305 mm - long
421 mm - long,
12.2 mm - head diameter
92.9 mm - long, 18.9 mm - diameter
Integral 3-pin XLRM-type
3m long, 3.2mm diameter,
2-conductor shielded cable with
TA3F-type connector
UE-C cardioid (120°)
UE-H hypercardioid (100°)
UE-O omnidirectional (360°)
UE-UL UniLine™ (90°)
AT8538 power module;
AT8153 two-stage foam windscreen
Cable
10 dB
20k10k5k2k1k50020010050
8 kHz
200 Hz
1 kHz
5 kHz
0°
330°
300°
270°
240°
210°
180°
150°
120°
90°
60°
30°
Optional Accessories:
AT8601 Desk stand.
AT8614 Desk stand with thru-hole.
AT8506 four-channel 48V phantom power
supply (AC powered).
AT8801/EU single-channel 48V phantom
power supply (AC powered).
Polar Pattern
Frequency Response
SCALE IS 5 DECIBELS PER DIVISION
LEGEND
Frequency in Hertz
LEGEND
12” or more on axis
Roll-off
Response in dB
FORM No. ATGC-L0004-05-E
Machida • Tokyo • Japan
