CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

AX-ADCH03

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 9/24/18 INSTAX-ADCH03

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun, solder,

and heat shrink • Small flat-blade screwdriver

• Tape • Wire cutter • Zip ties

TABLE OF CONTENTS

Connections to be made

For models

without

an amplifier .......................3

For models

with

an amplifier ............................4

Installing & programming the AX-ADCH03

AX-ADBOX1 ...........................................................5

AX-ADBOX2 ..........................................................6

Adjusting the AX-ADCH03 .....................................7

Chrysler Data Interface2013-up*

APPLICATIONS

See inside front cover

• Provides accessory power (12-volt 10-amp)

• Maintains the retained accessory power (R.A.P.) feature

• Can be used in non-amplified, or amplified models

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness (ASWC-1 sold separately)

• Retains the factory backup camera†

• Retains the factory AUX-IN jack

• Retains balance and fade*

• Micro “B” USB updatable

• AX-ADCH03 harness

*Visit AxxessInterfaces.com for up-to-date vehicle specific applications.

INTRODUCTION

The AX-ADCH03 harness is designed for, and must be used with, the

AX-ADBOX1 or AX-ADBOX2 interface (sold separately). Please refer to the

AX-ADBOX1 or AX-ADBOX2 for the 16-pin connector with stripped leads.

† Only if the camera is displayed on the factory radio

* To retain fade in amplified models, use the AX-ADBOX1
