Fiat Family 2015-up*

INTERFACE FEATURES

• “Plug & Play” harness for the AX-ADDCAM interface (sold separately)

•

Reverse signal trigger generated via CAN bus communication of the vehicle

•

Turn signal trigger generated via CAN bus communication of the vehicle

• (4) Programmable camera control wires (conﬁgured through the

Axxess Updater program)

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun, solder, and heat shrink

• Tape • Wire cutter • Zip ties

CONNECTIONS

• For vehicles

with

a factory camera: The camera signal will need to be

interrupted and connected to the corresponding input/output RCA jacks

on the AX-ADDCAM interface.

•

Connect the RCA jack from the AX-ADDCAM-CH6 labeled “Camera

output”, to the RCA jack on the AX-ADDCAM interface labeled “Camera 1”.

•

Connect the RCA jack from the AX-ADDCAM-CH6 labeled “Camera input”,

to the RCA jack on the AX-ADDCAM interface labeled “Camera output”.

• For vehicles

without

a factory camera:

• Connect the RCA jack on the AX-ADDCAM-CH6 labeled “Camera input”, to

the RCA jack on the AX-ADDCAM interface labeled “Camera output”.

• Disregard the RCA jack labeled “Camera output”, it will not be used in

this application.

•

Disregard the following (2) wires, they will not be used in this application:

Blue/Green

labeled “VSS input”,

Green/Red

labeled “VSS output”

ANALOG CONTROL TRIGGER WIRES

• The optional analog control wires can be activated with either a negative

or positive trigger depending on how they are conﬁgured in the Axxess

Updater program. These wires will only be used if manual control of the

cameras will be desired. Otherwise tape off and disregard these wires.

Fiat Family 2015-up*

INTERFACE FEATURES

• “Plug & Play” harness for the AX-ADDCAM interface (sold separately)

•

Reverse signal trigger generated via CAN bus communication of the vehicle

•

Turn signal trigger generated via CAN bus communication of the vehicle

• (4) Programmable camera control wires (conﬁgured through the

Axxess Updater program)

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun, solder, and heat shrink

• Tape • Wire cutter • Zip ties

CONNECTIONS

• For vehicles

with

a factory camera: The camera signal will need to be

interrupted and connected to the corresponding input/output RCA jacks

on the AX-ADDCAM interface.

•

Connect the RCA jack from the AX-ADDCAM-CH6 labeled “Camera

output”, to the RCA jack on the AX-ADDCAM interface labeled “Camera 1”.

•

Connect the RCA jack from the AX-ADDCAM-CH6 labeled “Camera input”,

to the RCA jack on the AX-ADDCAM interface labeled “Camera output”.

• For vehicles

without

a factory camera:

• Connect the RCA jack on the AX-ADDCAM-CH6 labeled “Camera input”, to

the RCA jack on the AX-ADDCAM interface labeled “Camera output”.

• Disregard the RCA jack labeled “Camera output”, it will not be used in

this application.

•

Disregard the following (2) wires, they will not be used in this application:

Blue/Green

labeled “VSS input”,

Green/Red

labeled “VSS output”

ANALOG CONTROL TRIGGER WIRES

• The optional analog control wires can be activated with either a negative

or positive trigger depending on how they are conﬁgured in the Axxess

Updater program. These wires will only be used if manual control of the

cameras will be desired. Otherwise tape off and disregard these wires.

Fiat Family 2015-up*

INTERFACE FEATURES

• “Plug & Play” harness for the AX-ADDCAM interface (sold separately)

•

Reverse signal trigger generated via CAN bus communication of the vehicle

•

Turn signal trigger generated via CAN bus communication of the vehicle

• (4) Programmable camera control wires (conﬁgured through the

Axxess Updater program)

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun, solder, and heat shrink

• Tape • Wire cutter • Zip ties

CONNECTIONS

• For vehicles

with

a factory camera: The camera signal will need to be

interrupted and connected to the corresponding input/output RCA jacks

on the AX-ADDCAM interface.

•

Connect the RCA jack from the AX-ADDCAM-CH6 labeled “Camera

output”, to the RCA jack on the AX-ADDCAM interface labeled “Camera 1”.

•

Connect the RCA jack from the AX-ADDCAM-CH6 labeled “Camera input”,

to the RCA jack on the AX-ADDCAM interface labeled “Camera output”.

• For vehicles

without

a factory camera:

• Connect the RCA jack on the AX-ADDCAM-CH6 labeled “Camera input”, to

the RCA jack on the AX-ADDCAM interface labeled “Camera output”.

• Disregard the RCA jack labeled “Camera output”, it will not be used in

this application.

•

Disregard the following (2) wires, they will not be used in this application:

Blue/Green

labeled “VSS input”,

Green/Red

labeled “VSS output”

ANALOG CONTROL TRIGGER WIRES

• The optional analog control wires can be activated with either a negative

or positive trigger depending on how they are conﬁgured in the Axxess

Updater program. These wires will only be used if manual control of the

cameras will be desired. Otherwise tape off and disregard these wires.

*Visit AxxessInterfaces.com for up-to-date vehicle speciﬁc applications. *Visit AxxessInterfaces.com for up-to-date vehicle speciﬁc applications. *Visit AxxessInterfaces.com for up-to-date vehicle speciﬁc applications.

INSTALLATION

• Conﬁgure the AX-ADDCAM interface following the installation instructions

included with the AX-ADDCAM interface. Failure to conﬁgure the interface

will result in the interface not functioning properly.

• Remove the main harness from the factory radio, then install the

AX-ADDCAM-CH6 in between.
