AXAMP-TY4
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 2/5/25 INSTAXAMP-TY4
INTERFACE FEATURES
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape
• Wire cutter
• Zip-ties
• Multimeter
TABLE OF CONTENTS
Installation & Installation Options ........................2
Adding Amp(s) to a Factory System ....................3
Troubleshooting.....................................................4
APPLICATIONS
Visit AxxessInterfaces.com for current application list
INTERFACE COMPONENTS
• AXAMP-TY4 Amplifier Integration interface
• AXAMP-TY4 vehicle T-harness
• Bass knob
Amplifier Integration Interface
Fits Toyota
2011-2022
www.MetraOnline.com
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal before
installing this product. Ensure that all installation
connections, especially the air bag indicator lights, are
plugged in before reconnecting the battery or cycling
the ignition to test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
• Designed for amplified models
• Provides 6 channels of 5-volt RMS audio
• Non-fading full range output (Channels 5 & 6)
• Includes plug-n-play harnessing
• Simple behind the radio installation
• No programming required
• Dual colored LED
• Input: 50 Watts per channel
• Amp turn-on trigger (DC) 250mA
• 2 channel S/PDIF out (Front)
For Dash Disassembly Instructions, refer to
Metraonline.com. Enter the year, make, and
model of the vehicle in the Vehicle Fit Guide
for Radio Install kits.
