AXDIS-TY1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 4/22/24 INSTAXDIS-TY1
ATTENTION: With the key out of the ignition, disconnect
the negative battery terminal before installing this product.
Ensure that all installation connections, especially the air
bag indicator lights, are plugged in before reconnecting the
battery or cycling the ignition to test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
INTERFACE FEATURES
INTERFACE COMPONENTS
• Wire cutter
• Crimp tool
• Solder gun
• Tape
• Small flat-blade screwdriver
• Connectors (example: butt-
connectors, bell caps, etc.)
TABLE OF CONTENTS
Applications ...........................................................2
Connections:
Non-Amplified Models:
LD-TYNOAMP .................3
Amplified Models: LD-BX-TY2
.............................4
3.5mm Jack Steering Wheel Control Retention
....5
Installing the AXDIS-TY1 ........................................5
Programming the AXDIS-TY1 ................................6
Audio Level Adjustment .......................................6
Steering Wheel Control Settings .....................7-10
LED Feedback .......................................................7
Changing Radio Type ..........................................8
Remapping the SWC Buttons .........................8-9
Dual Assignment Instructions
........................... 10
Troubleshooting.................................................... 11
Lexus/Toyota Interface with SWC 2002-2015
• AXDIS-TY1 interface
• AXDIS-TY1 harnesses (LD-TYNOAMP, LD-BX-TY2 AND LD-2NAVAMP)
• Female 3.5mm connector with stripped leads
Visit AxxessInterfaces.com for more detailed information
about the product and up-to-date vehicle specific applications.
• Designed for both amplified and non-amplified models
• Provides accessory power (12-volt 10-amp)
• Retains audio controls on the steering wheel
• Provides NAV outputs (parking brake, reverse)
• Retains the factory AUX-IN jack
• Retains balance on amplified models
(non-amplifed models will retain balance and fade)
• Micro-B USB updatable
APPLICATIONS (See Page 2)
Product Info
TOOLS REQUIRED
2
APPLICATIONS
LEXUS
ES Series ............................................................... 2007-2012
ES Series (w/ multi disc) ..................................... 2002-2006
IS Series ................................................................ 2002-2005
RX Series ............................................................... 2004-2008
TOYOTA
4-Runner .............................................................. 2003-2013
Avalon ................................................................... 2011-2012
(Camry) Solara ..................................................... 2004-2008
Camry (w/o nav) ................................................ 2012-2013
Camry.................................................................... 2007-2011
Corolla ................................................................... 2003-2011
FJ Cruiser............................................................... 2011-2014
Highlander ............................................................ 2008-2013
Matrix .................................................................... 2005-2012
Prius 3rd Gen (w/o nav) ...................................... 2012-2015
TOYOTA (CONT)
Plug-In (PHV) (w/o nav) ..................................... 2012-2015
Prius ...................................................................... 2004-2011
Rav-4 .................................................................... 2004-2014.5
Sequoia (w/o nav)............................................... 2013
Sequoia ................................................................. 2005-2012
Sienna ................................................................... 2004-2014
Tacoma ................................................................. 2005-2013
Tundra ................................................................... 2006-2013
Tundra (Double Cab) ........................................... 2004-2005
Venza (w/ SD card based nav) ........................... 2013-2014
Venza .................................................................... 2009-2012
APPLICATIONS
