Seite 1/4
AXSSO-CH
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 12/8/22 INSTAXSSO-CH
Product Info
INTERFACE FEATURES
INTRODUCTION
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Zip ties • Cutters (for zip ties)
• Micro-B USB cable
(Axxess part number AXUSB-MCBL)
TABLE OF CONTENTS
Programming .........................................................2
Connections ............................................................3
Operation ................................................................4
Chrysler Stop/Start Override Interface
2015-Up
APPLICATIONS
• Allows the override of the STOP/START engine feature
• The factory STOP/START button can resume the STOP/START feature
• Can be used with either a factory or aftermarket radio
•
Vehicle type configured through the Axxess Updater software program
• Simple plug n’ play installation, no wiring required
The AXSSO-CH is designed to disengage the STOP/START feature of the vehicle, and keep that feature disengaged even after the key has been
cycled. The AXSSO-CH will work with either an aftermarket radio, or a factory radio. A simple plug n’ play installation is all that is required to install
the device in the vehicle, and programming through a Windows 10 computer via the Axxess Updater software program.
Chrysler
Pacifica 2018-Up
Dodge
Durango 2016-2017
Jeep
Cherokee 2016-2018
Gladiator 2020-Up
Grand Cherokee 2015-2017
Wrangler 2019-Up
• AXSSO-CH interface
• AXSSO-CH harness (qty. 2)
2
PROGRAMMING
(Figure A) (Figure B) (Figure C)
1.
2.
3.
4.
Download and install the Axxess Updater software program from:
axxessinterfaces.com/resources/updater-software
On the next screen that opens, select the year, make, and model of the
vehicle, then press Program Interface. (Figure B)
Connect the micro-B USB cable (sold separately) to the computer and
AXSSO-CH interface. Open the Axxess Updater software program and
wait until the word is shown in the bottom left of the screen. Ready
Select . (Figure A)Stop / Start
When the Configuration Successful box pops up, the programming
process is complete. (Figure C)
Continue to Installation
3
REV. 12/8/22 INSTAXSSO-CH
INSTALLATION
These vehicles will connect to the wiring harness located at the radio location.
Chrysler
Pacifica 2017
• Disassembly instructions: metraonline.com/part/99-6543HG
Dodge
Durango 2016-Up
• Disassembly instructions: metraonline.com/part/99-6537B
Jeep
Cherokee 2016-Up
• Disassembly instructions: metraonline.com/part/99-6518B
Grand Cherokee 2015-Up
• Disassembly instructions: metraonline.com/part/99-6536S
From the wiring harness in the vehicle behind the radio:
1. Unplug the main connector from the radio.
2. Plug the AXSSO-CH harness in between the and .radio radio harness
3. Plug the AXSSO-CH harness into the AXSSO-CH interface.
These vehicles will connect to the hazard switch in the dashboard.
Chrysler
Pacifica 2018-Up
• Disassembly instructions: metraonline.com/part/99-6543HG
Jeep
Wrangler 2019-Up
• Disassembly instructions: N/A
Gladiator 2020-Up
• Disassembly instructions: N/A
From the hazard switch:
1. Unplug the connector from the hazard switch.
2. Plug the AXSSO-CH harness in between the hazard switch
and .hazard switch harness
3. Plug the AXSSO-CH harness into the AXSSO-CH interface.
To Hazard
Switch
To Hazard
Switch Harness
To
Radio
To Radio
Harness
