AX-ALOC648

AX-ALOC648

AX-ALOC648

AX-ALOC648

AX-ALOC648

AX-ALOC648

INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS

INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.

Wire Color & Function: The audio input wire colors are an EIA

standard for car stereo applications as follows:

WHITE = LEFT Front (+) Input

WHITE /BLACK = LEFT Front (-) Input

GRAY = RIGHT Front (+) Input

GRAY/BLACK= RIGHT Front (-) Input

GREEN= LEFT Rear (+) Input

GREEN/BLACK = LEFT rear (-) Input

PURPLE= RIGHT Rear (+) Input,

PURPLE/BLACK = RIGHT Rear (-) Input

BLACK = Reference Ground (-)

(REFERENCE GROUND OPTIONAL IF NOISE IS PRESENT)

NOTE: Be sure that all audio input connections are polarized or in

phase with each other. That is, the positive output wires from the

audio source need to be connected to the corresponding positive

input wires of the AX-ALOC648. The same goes for the negative

audio wires. Failure to do this will result in poor bass response and

low quality audio.

Adjusting the AX-ALOC648 for maximum performance:

After completing all of the necessary connections turn the AX-

ALOC648 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and

adjust the main volume control on the stereo to approximately 3/4

maximum volume. Select one of the adjustment pots on the AX-

ALOC648 and turn it slowly clockwise until you notice audio distor-

tion and then stop. Turn the remaining pot to the same position as

the previously adjusted pot. The audio set-up of the AX-ALOC648 is

now complete and ready to be enjoyed.
