AXAC-CH4

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 5/14/25 INSTAXAC-CH4

TOOLS REQUIREDINTERFACE COMPONENTSREQUIRED ITEMS

TABLE OF CONTENTS

Introduction ...........................................................2

Interface Features ..................................................2

Configuration .....................................................2-4

Connections ............................................................5

Installation .............................................................6

Programming .........................................................7

• Crimping tool and connectors, or solder gun, solder, and heat

shrink • Tape • Wire cutter • Zip ties

• AXAC-CH4 interface

• AXAC-CH4 interface harness

• AXAC-CH4 vehicle harness (qty. 2)

• 22-pin T-harness

•

22-pin T-harness (cam harness)

Update Cable: AXUSB-MCBL

(sold separately

)

Axxess Updater Program

*Radio models # RB2, RBZ, REN, REW, REP, RER, REZ, RHB, RHR, RHWRHWRHP

Camera Interface With Pre-Wired

Harness

Fits Select Chrysler Models

2007-2018*

APPLICATIONS

Chrysler

300 .....................................................2008-2010

Dodge

Challenger .........................................2008-2014

Durango ...............................................2011-2013

Jeep

Liberty** .............................................2008-2011

Wrangler (JK) ....................................2007-2018

**With MyGig Radio

Note: Only compatible with NTSC cameras.

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle specific applications

ATTENTION:

With the key out of the ignition,

disconnect the negative battery terminal before

installing this product. Ensure that all installation

connections, especially the air bag indicator

lights, are plugged in before reconnecting the

battery or cycling the ignition to test this product.

NOTE:

Refer also to the instructions included

with the aftermarket accessory before installing

this device.

INTERFACE FEATURES

(see next page)
