AXDI-SP1

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 8/8/23 INSTAXDI-SP1

ATTENTION: With the key out of the

ignition, disconnect the negative battery

terminal before installing this product.

Ensure that all installation connections,

especially the air bag indicator lights, are

plugged in before reconnecting the battery

or cycling the ignition to test this product.

NOTE: Refer also to the instructions

included with the aftermarket accessory

before installing this device.

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections ........................................................2-3

LD-AXVI-SP1 DIAGRAM ......................................2

LD-AXVI-SP2 DIAGRAM .....................................3

Installation .............................................................4

Programming .........................................................4

Dodge/Mercedes/Freightliner

Accessory and NAV Outputs 2007-UP

• Provides accessory (12-volt 10-amp)

• Retains R.A.P. (Retained Accessory Power)

•

Provides wires for multimedia radios (park brake, reverse, speed sense)

• Prewired AXSWC harness included+ (AXSWC sold separately)

• High level speaker input

• USB updatable

• AXDI-SP1 interface

• LD-AX-XSVI-SP1 harness

• LD-AX-XSVI-SP2 harness

APPLICATIONS

Dodge

Sprinter ....................................................2007

Sprinter (Sound 5 radio) ...............2008-2009

Mercedes

Sprinter (Sound 5 radio) ................2010-2013

Freightliner

Sprinter ....................................................2007

Sprinter (Sound 5 radio) ..................2008-UP

Visit AxxessInterfaces.com

for more detailed information about the product

and up-to-date vehicle specific applications
