AXDIS-MZ1

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/22/24 INSTAXDIS-MZ1

INTERFACE FEATURES

INTERFACE COMPONENTSTOOLS REQUIRED

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

TABLE OF CONTENTS

Connections ........................................................2-4

For models

without

an amplifier .......................2

For models

with

an amplifier.............................3

3.5mm jack steering wheel control retention ..4

Installing the AXDIS-MZ1 .......................................4

Programming the AXDIS-MZ1 ...............................5

Steering wheel control (SWC) settings............5-8

LED feedback .......................................................5

Changing radio type ...........................................6

Remapping the (SWC) buttons ..........................6-7

Dual assignment instructions ....................................7-8

Troubleshooting.....................................................8

Fits Mazda Data Interface with SWC 2007-2015

APPLICATIONS

• Designed for both amplified and non-amplified models

• Provides NAV outputs (parking brake, reverse, speed sense)

• Retains audio controls on the steering wheel

• Retains balance and fade (excludes amplified models)

• Retains the ability to set the clock with a service harness

• Micro-B USB updatable

MAZDA

CX-7 .............................................................................................2007-2012

CX-9 .............................................................................................2007-2010

CX-9 ..............................................................................................2013-2015

• AXDIS-MZ1 interface

• AXDIS-MZ1 harness

• 16-pin harness with stripped leads

• Female 3.5mm connector with stripped leads

MetraOnline.com may be used

to assist with dash assembly

instructions. Simply enter your

Year, Make, Model vehicle into

the vehicle fit guide and look

for the Dash Kit Installation

Instructions.

Product Info

www.MetraOnline.com

ATTENTION: With the key out of the ignition,

disconnect

the negative battery terminal before installing

this product. Ensure that all installation connections,

especially the air bag indicator lights, are plugged in

before reconnecting the

battery or cycling the ignition to

test this product.

NOTE: Refer also to the instructions included with the

aftermarket accessory before installing this device.

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle specific applications.
