AXTC-FD2

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 3/10/23 INSTAXTC-FD2

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip-ties

TABLE OF CONTENTS

Connections ............................................................2

Programming .........................................................3

Troubleshooting .....................................................4

Ford SWC (Steering Wheel Control)

and Data Interface 2012-2020

APPLICATIONS

• Provides accessory power (10-

amp)

• Provides wires for multimedia

radios (park brake, reverse,

speed sense)

• Retains audio controls on the

steering wheel

• Designed to be compatible with

all major radio brands

•

Auto detects vehicle type, radio

connection, and preset controls

• Ability to dual assign steering

wheel control buttons

• Retains memory settings even

after battery disconnection or

interface removal (non volatile

memory)

• Provides illumination output

•

Retains the 3.5mm AUX-IN jack

• USB Micro-B updatable

• Includes 5V factory amplifier

step-down

Ford (1)

Escape ....................................2013-2016

Fiesta ......................................2011-2019

Focus ...................................... 2012-2014

Ranger ..................................2019-2020

Transit 150/250/350 .............. 2015-2019

Transit Connect .....................2014-2016

(1) This interface must be used along with the corresponding Metra radio-install-kit (sold separately)

• AXTC-FD2 interface • AXTC-FD2 harness

• 3.5mm adapter

• LD-AFDI-5V amplifier step-down

Visit AxxessInterfaces.com for more detailed information about the product and

up-to-date vehicle specific applications

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections are secure before

cycling the ignition to test this product.

NOTE: Refer to the instructions included with

the aftermarket radio.
