Seite 1/68

FCC Informaon and Copyright

This equipment has been tested and found to comply with the limits of a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon

against harmful interference in a residenal installaon. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instrucons,

may cause harmful interference to radio communicaons. There is no guarantee that interference

will not occur in a parcular installaon.

The vendor makes no representaons or warranes with respect to the contents here and

specially disclaims any implied warranes of merchantability or tness for any purpose. Further

the vendor reserves the right to revise this publicaon and to make changes to the contents here

without obligaon to nofy any party beforehand.

Duplicaon of this publicaon, in part or in whole, is not allowed without rst obtaining the

vendor’s approval in wring.

The content of this user’s manual is subject to be changed without noce and we will not be

responsible for any mistakes found in this user’s manual. All the brand and product names are

trademarks of their respecve companies.

Dichiarazione di conformità sinteca

Ai sensi dell’art. 2 comma 3 del D.M. 275 del

30/10/2002

Si dichiara che questo prodoo è conforme

alle normave vigen e soddisfa i requisi

essenziali richies dalle direve

2004/108/CE, 2006/95/CE e 1999/05/CE

quando ad esso applicabili

Short Declaraon of conformity

We declare this product is complying with the

laws in force and meeng all the essenal

requirements as specied by the direcves

2004/108/CE, 2006/95/CE and 1999/05/CE

whenever these laws may be applied

2 | Table Of Contents

Table Of Contents

FCC Informaon and Copyright �� 1

Chapter 1: Introducon �� 3

1.1 Before You Start .................................................................................................................. 3

1.2 Package Checklist ................................................................................................................ 3

1.3 Specicaons ...................................................................................................................... 4

1.4 Rear Panel Connectors ........................................................................................................ 5

1.5 Motherboard Layout .......................................................................................................... 6

Chapter 2: Hardware installaon �� 8

2.1 Install Central Processing Unit (CPU) .................................................................................. 8

2.2 Install a Heatsink ................................................................................................................. 9

2.3 Connect Cooling Fans ....................................................................................................... 11

2.4 Install System Memory ..................................................................................................... 11

2.5 Expansion Slots ................................................................................................................. 14

2.6 Jumper & Switch Seng ................................................................................................... 15

2.7 Headers & Connectors ...................................................................................................... 16

Chapter 3: UEFI BIOS & Soware �� 19

3.1 UEFI BIOS Setup ................................................................................................................ 19

3.2 BIOS Update ...................................................................................................................... 19

3.3 Soware ............................................................................................................................ 23

Chapter 4: Useful help�� 26

4.1 Driver Installaon ............................................................................................................. 26

4.2 AMI BIOS Beep Code......................................................................................................... 27

4.3 AMI BIOS post code .......................................................................................................... 27

4.4 Troubleshoong ................................................................................................................ 29

4.5 RAID Funcons .................................................................................................................. 30

APPENDIX I: Specicaons in Other Languages �� 32

Arabic ...................................................................................................................................... 32

German ................................................................................................................................... 33

Russian .................................................................................................................................... 34

Spanish ................................................................................................................................... 35

Thai ......................................................................................................................................... 36

Produktspezifikationen

Marke:	Biostar
Kategorie:	Wandsteckdose
Modell:	B450MH
Prozessorhersteller:	AMD
Breite:	198 mm
Tiefe:	244 mm
Mitgelieferte Kabel:	SATA
Anzahl USB 2.0 Anschlüsse:	2
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Warentarifnummer (HS):	84733020
Betriebsanleitung:	Ja
Anzahl HDMI-Anschlüsse:	1
Audio Kanäle:	7.1 Kanäle
RAID Level:	0, 1,10
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	4
Thermal Design Power (TDP):	105 W
Prozessorsockel:	Sockel AM4
Anzahl VGA (D-Sub) Anschlüsse:	1
Kompatible Prozessoren:	AMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximale Anzahl an SMP-Prozessoren:	1
Motherboardformfaktor:	micro ATX
Motherboard Chipsatz Familie:	AMD
Motherboard Chipsatz:	AMD B450
Audio-Chip:	Realtek ALC887
Komponente für:	PC
Unterstützte Arbeitsspeicher:	DDR4-SDRAM
Anzahl der Speichersteckplätze:	2
Arbeitsspeicher Typ:	DIMM
Speicherkanäle:	Zweikanalig
Unterstützte Arbeitsspeichergeschwindigkeit:	1866,2133,2400,2667,2933,3200 MHz
RAM-Speicher maximal:	32 GB
Anzahl der M.2 (M)-Steckplätze:	1
PCI-Express x16 (Gen 3.x)-Anschlüsse:	1
PCI-Express x1 (Gen 2.x)-Anschlüsse:	2
Treiber enthalten:	Ja
Anzahl PS/2 Anschlüsse:	1
ATX Stromstecker (24-pol.):	Ja
SATA III Anschlüsse:	4
Anzahl USB 2.0 Schnittstellen:	2
CPU Ventilatorstecker:	Ja
Front Panel Audiostecker:	Ja
Frontpanel-Stecker:	Ja
USB 3.2 Gen 1 (3.1 Gen 1) Anschlüsse:	1
Clear CMOS-Jumper:	Ja
BIOS-Typ:	AMI
Ethernet Schnittstellen Typ:	Gigabit Ethernet
LAN-Controller:	Realtek RTL8111H
EPS Stromstecker (8-pin):	Ja
Zahl der COM Stecker:	1
Unterstützte Speichermodulkapazitäten:	8GB, 16GB
Ethernet/LAN:	Ja
