Biostar B760MZ-E PRO Bedienungsanleitung

Biostar Wandsteckdose B760MZ-E PRO

Lies die bedienungsanleitung für Biostar B760MZ-E PRO (166 Seiten) kostenlos online; sie gehört zur Kategorie Wandsteckdose. Dieses Handbuch wurde von 2 Personen als hilfreich bewertet und erhielt im Schnitt 4.8 Sterne aus 1.5 Bewertungen. Hast du eine Frage zu Biostar B760MZ-E PRO oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage

Download PDF

Seite 1/166

FCC Informaon and Copyright

This equipment has been tested and found to comply with the limits of a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon

against harmful interference in a residenal installaon. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instrucons,

may cause harmful interference to radio communicaons. There is no guarantee that interference

will not occur in a parcular installaon.

The vendor makes no representaons or warranes with respect to the contents here and

specially disclaims any implied warranes of merchantability or tness for any purpose. Further

the vendor reserves the right to revise this publicaon and to make changes to the contents here

without obligaon to nofy any party beforehand.

Duplicaon of this publicaon, in part or in whole, is not allowed without rst obtaining the

vendor’s approval in wring.

The content of this user’s manual is subject to be changed without noce and we will not be

responsible for any mistakes found in this user’s manual. All the brand and product names are

trademarks of their respecve companies.

Dichiarazione di conformità sinteca

Ai sensi dell’art. 2 comma 3 del D.M. 275 del

30/10/2002

Si dichiara che questo prodoo è conforme

alle normave vigen e soddisfa i requisi

essenziali richies dalle direve

2004/108/CE, 2006/95/CE e 1999/05/CE

quando ad esso applicabili

Short Declaraon of conformity

We declare this product is complying with the

laws in force and meeng all the essenal

requirements as specied by the direcves

2004/108/CE, 2006/95/CE and 1999/05/CE

whenever these laws may be applied

The terms HDMI and HDMI High-Denion Mulmedia Interface, and the HDMI Logo are trademarks or

registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

2 | Table Of Contents

Table Of Contents

FCC Informaon and Copyright �� 1

Chapter 1: Introducon �� 3

1.1 Before You Start .................................................................................................................. 3

1.2 Package Checklist ................................................................................................................ 3

1.3 Specicaons ...................................................................................................................... 4

1.4 Rear Panel Connectors ........................................................................................................ 6

1.5 Motherboard Layout .......................................................................................................... 8

Chapter 2: Hardware installaon �� 12

2.1 Install Central Processing Unit (CPU) ................................................................................ 12

2.2 Install a Heatsink ............................................................................................................... 14

2.3 Connect Cooling Fans ....................................................................................................... 15

2.4 Install System Memory ..................................................................................................... 16

2.5 Expansion Slots ................................................................................................................. 17

2.6 Jumper & Switch Seng ................................................................................................... 20

2.7 Headers & Connectors ...................................................................................................... 21

2.8 LEDs .................................................................................................................................. 26

Chapter 3: UEFI BIOS & Soware �� 27

3.1 UEFI BIOS Setup ................................................................................................................ 27

3.2 BIOS Update ...................................................................................................................... 27

3.3 Soware ............................................................................................................................ 32

Chapter 4: Useful help�� 35

4.1 Driver Installaon ............................................................................................................. 35

4.2 AMI BIOS Beep Code......................................................................................................... 36

4.3 AMI BIOS post code .......................................................................................................... 36

4.4 Troubleshoong ................................................................................................................ 38

APPENDIX I: Specicaons in Other Languages �� 39

Arabic ...................................................................................................................................... 39

German ................................................................................................................................... 41

Spanish ................................................................................................................................... 43

Thai ........................................................................................................................................ 45

Japan ....................................................................................................................................... 47

Produktspezifikationen

Marke:	Biostar
Kategorie:	Wandsteckdose
Modell:	B760MZ-E PRO
Prozessorhersteller:	Intel
WLAN:	Nein
Breite:	244 mm
Tiefe:	244 mm
Mitgelieferte Kabel:	SATA
Anzahl USB 2.0 Anschlüsse:	2
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Anzahl HDMI-Anschlüsse:	1
Audio Kanäle:	7.1 Kanäle
Unterstützt Windows-Betriebssysteme:	Windows 10 x64, Windows 11 x64
Unterstützte Speicherlaufwerke:	HDD & SSD
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	3
Prozessorsockel:	LGA 1700
Anzahl VGA (D-Sub) Anschlüsse:	1
Kompatible Prozessoren:	Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9
Maximale Anzahl an SMP-Prozessoren:	1
Motherboardformfaktor:	micro ATX
Motherboard Chipsatz Familie:	Intel
Motherboard Chipsatz:	Intel B760
Audio-Chip:	Realtek ALC897
Komponente für:	PC
PC Gesundheitsüberwachung:	FAN, Temperature, Voltage
Unterstützte Arbeitsspeicher:	DDR5-SDRAM
Anzahl der Speichersteckplätze:	4
Arbeitsspeicher Typ:	DIMM
Speicherkanäle:	Zweikanalig
Unterstützte Arbeitsspeichergeschwindigkeit:	5000,5200,5400,5600,5800,6000 MHz
RAM-Speicher maximal:	128 GB
Unterstützte Speicherlaufwerk-Schnittstellen:	M.2, SATA III
Anzahl der M.2 (M)-Steckplätze:	1
PCI-Express x16 (Gen 3.x)-Anschlüsse:	1
Anzahl PS/2 Anschlüsse:	1
Anzahl DVI-D-Anschlüsse:	1
ATX Stromstecker (24-pol.):	Ja
SATA III Anschlüsse:	4
Anzahl USB 2.0 Schnittstellen:	2
CPU Ventilatorstecker:	Ja
Front Panel Audiostecker:	Ja
Frontpanel-Stecker:	Ja
RGB-LED-Stiftleiste:	Ja
USB 3.2 Gen 1 (3.1 Gen 1) Anschlüsse:	1
Ethernet Schnittstellen Typ:	2.5 Gigabit Ethernet
LAN-Controller:	Realtek RTL8125B
Anzahl DisplayPort Anschlüsse:	1
PCI-Express x1 (Gen 3.x)-Anschlüsse:	1
EPS Stromstecker (8-pin):	Ja
USB 3.2 Gen 2 (3.1 Gen 2) Anschlüsse:	1
PCI Express x16-Steckplätze (Gen 4.x):	1
Ethernet/LAN:	Ja
TPM-Anschluss:	Ja
