FCC Informaon and Copyright

This equipment has been tested and found to comply with the limits of a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon

against harmful interference in a residenal installaon. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instrucons,

may cause harmful interference to radio communicaons. There is no guarantee that interference

will not occur in a parcular installaon.

The vendor makes no representaons or warranes with respect to the contents here and

specially disclaims any implied warranes of merchantability or tness for any purpose. Further

the vendor reserves the right to revise this publicaon and to make changes to the contents here

without obligaon to nofy any party beforehand.

Duplicaon of this publicaon, in part or in whole, is not allowed without rst obtaining the

vendor’s approval in wring.

The content of this user’s manual is subject to be changed without noce and we will not be

responsible for any mistakes found in this user’s manual. All the brand and product names are

trademarks of their respecve companies.

Dichiarazione di conformità sinteca

Ai sensi dell’art. 2 comma 3 del D.M. 275 del

30/10/2002

Si dichiara che questo prodoo è conforme

alle normave vigen e soddisfa i requisi

essenziali richies dalle direve

2004/108/CE, 2006/95/CE e 1999/05/CE

quando ad esso applicabili

Short Declaraon of conformity

We declare this product is complying with the

laws in force and meeng all the essenal

requirements as specied by the direcves

2004/108/CE, 2006/95/CE and 1999/05/CE

whenever these laws may be applied

2 | Table Of Contents

Table Of Contents

FCC Informaon and Copyright �� 1

Chapter 1: Introducon �� 3

1.1 Before You Start .................................................................................................................. 3

1.2 Package Checklist ................................................................................................................ 3

1.3 Specicaons ...................................................................................................................... 4

1.4 Rear Panel Connectors ........................................................................................................ 5

1.5 Motherboard Layout .......................................................................................................... 6

Chapter 2: Hardware installaon �� 7

2.1 Connect Cooling Fans ......................................................................................................... 7

2.2 Install System Memory ....................................................................................................... 7

2.3 Expansion Slots ................................................................................................................... 9

2.4 Jumper & Switch Seng ................................................................................................... 10

2.5 Headers & Connectors ...................................................................................................... 11

Chapter 3: UEFI BIOS & Soware �� 14

3.1 UEFI BIOS Setup ................................................................................................................ 14

3.2 BIOS Update ...................................................................................................................... 14

3.3 Soware ............................................................................................................................ 18

Chapter 4: Useful help�� 19

4.1 Driver Installaon ............................................................................................................. 19

4.2 AMI BIOS Beep Code......................................................................................................... 20

4.3 AMI BIOS post code .......................................................................................................... 20

4.4 Troubleshoong ................................................................................................................ 22

APPENDIX I: Specicaons in Other Languages �� 23

Arabic ...................................................................................................................................... 23

German ................................................................................................................................... 24

Russian .................................................................................................................................... 25

Spanish ................................................................................................................................... 26

Thai ......................................................................................................................................... 27

Produktspezifikationen

Marke:	Biostar
Kategorie:	Nicht kategorisiert
Modell:	J4125NHU
Prozessorhersteller:	Intel
Anzahl Prozessorkerne:	4
Breite:	170 mm
Tiefe:	170 mm
Anzahl USB 2.0 Anschlüsse:	2
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Anzahl HDMI-Anschlüsse:	1
Audio Kanäle:	7.1 Kanäle
Unterstützt Windows-Betriebssysteme:	Ja
Grafikkarte:	Intel® UHD Graphics 600
Prozessor:	J4125
Unterstützte Speicherlaufwerke:	HDD & SSD
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	2
Anzahl VGA (D-Sub) Anschlüsse:	1
Kompatible Prozessoren:	Intel® Celeron®
Maximale Anzahl an SMP-Prozessoren:	1
Motherboardformfaktor:	mini ITX
Motherboard Chipsatz Familie:	Intel
Audio-Chip:	Realtek ALC887
Komponente für:	PC
Unterstützte Arbeitsspeicher:	DDR4-SDRAM
Anzahl der Speichersteckplätze:	2
Arbeitsspeicher Typ:	DIMM
Speicherkanäle:	Zweikanalig
Unterstützte Arbeitsspeichergeschwindigkeit:	1866,2133,2400 MHz
RAM-Speicher maximal:	8 GB
Unterstützte Speicherlaufwerk-Schnittstellen:	M.2, PCI Express 2.0, SATA III
DirectX-Version:	12.0
Anzahl PS/2 Anschlüsse:	1
ATX Stromstecker (24-pol.):	Ja
SATA III Anschlüsse:	2
Anzahl USB 2.0 Schnittstellen:	2
Front Panel Audiostecker:	Ja
Frontpanel-Stecker:	Ja
BIOS-Typ:	UEFI
LAN-Controller:	Realtek RTL8111H
PCI-Express x16 (Gen 2.x)-Anschlüsse:	2
Maximaler interner Speicher, vom Prozessor unterstützt:	8 GB
Grafikkarte-Familie:	Intel
OpenGL-Version:	4.4
Maximale unterstützte Anzahl der HDD:	2
Anzahl Molex Anschlüsse 4pin:	1
Zahl der COM Stecker:	1
Ethernet/LAN:	Ja
