4K 60Hz 4:4:4 Video over 1Gb Network - Transmitter

IP300UHD-TX

Description

The Blustream IP300 series Video over IP distribution platform allows

virtually latency free (1 frame) distribution of 4K 18Gbps HDMI video

over a 1Gb managed network.

Featuring full interoperability with the IP350UHD product line where

Dante is required, the IP300UHD-TX is an industry leading 4K HDMI

transmitter that, using visually lossless compression technology,

delivers 18Gbps HDMI, HDCP2.2, audio, bi-directional IR, RS-232 & USB/

KVM up to lengths of 100m over standard copper network architecture,

or greater distances using the in-built bre SFP network interface.

The unit can be powered via PoE from the network switch, or locally

should the switch not support PoE.

With multiple conguration options available, the exibility of the

Blustream Video over IP solution makes this platform ideal for multiple

installation types.









Key Features

•

Advanced 4K HDMI 2.0 video over 1Gb managed network

supporting 18Gbps HDMI signals

• Virtually unlimited system size

• Extends HDMI up to a distance of 100m over a single CAT cable

• SFP port for signal distribution over bre

• Features 1 x HDMI loop-out for integrating local displays or

cascading to multiple devices

• Supports up to 4K UHD 60Hz 4:4:4

• AES-256 encryption of video signals across network

• Supports HDR including Dolby Vision LLM

• Supports all known HDMI audio formats including Dolby Atmos,

Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio

transmission

• Advanced signal management for independent routing of IR,

RS-232, USB/KVM, audio and video

• PoE (Power over Ethernet) to power Blustream unit from PoE

switch

• HDCP 2.2 compliant with advanced EDID management

• Audio breakout to analogue L/R audio, supporting both balanced

and unbalanced audio signals

• Balanced/unbalanced analogue audio input for replacing the

HDMI embedded audio with a dierent audio signal

• HDMI ARC, eARC or optical audio return from a display connected

to an IP300UHD or IP350UHD receiver

• OLED front panel display for advanced system information and

manual conguration

• Optional 24V power supply (should Ethernet switch not support

PoE)

• Compatible with Blustream IP300UHD-RX, IP300UHD-WP-TX, and

IP350UHD-TX/RX products

• IP300UHD/IP350UHD Multicast platform features 4 operational

modes:

- Matrix distribution (requires 1Gb network switch)

- Video wall (requires 1Gb network switch)

- One-to-one HDMI extender (no network switch required)

- One-to-many HDMI extender (no network switch required)

Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.

25mm

190mm

SFP24V1ALAN / PoEOPT OUTHDMI OUTHDMI IN

AUDIO IN

IP300UHD-TX

AUDIO OUT

IP300UHD-TX

Multicast 18Gbps UHD Transmitter

RESET

RS-232IR IN

RXTX

IR OUTUSB

DEBUG

ONOFF
