Description

Our NPA100DA networked audio zone amplier delivers advanced

audio integration within a commercial or residential AV installation.

The NPA100DA features a 2x 50W digital amplier (1 x 100W mono) or

70V / 100V hi-level constant voltage output, dedicated LFE sub-woofer

output, Dante audio integration and 2ch balanced / unbalanced

audio outputs.

The NPA100DA supports a variety of inputs including 2ch Dante

audio, HDMI ARC, MIC audio with 48V Phantom power support,

optical audio and 2ch balanced / unbalanced analogue audio.

The NPA100DA can be powered via PoE++ from a compatible network

switch, or locally should the switch not support PoE++. The unit also

includes the ability to lower the amplier power output subject to

PoE capabilities, support for combined or independent LAN and

Dante connections, DSP with a 31 band EQ, audio delay for lip sync

correction, independent gain control for audio inputs and control via

front panel, IR, RS-232, TCP/IP, Web Gui or 12V trigger.

NPA100DA

250mm250mm

70/100V



SUB

OUT



PHANTOM

Networked Power Amplier with Dante

Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.

ONOFF

5V 12V

TCP/IP

DANTE PoE

OPT

RS-232TRGIR IN

HDMI (ARC)

LINEMIC

L+L

-

-

R

-

R++L+L

--

R

-

R++

LINE

48V

HI-70V

LO-ZHI-100V

SUB

IR

+

-

BRIDGED

AUDIO INPUTAUDIO OUTPUT

CONTROL

SPEAKER OUTPUT

100VCOM70V

RXTXTSV

L

-

R

-

R+L+

MODE 1MODE 2

NETWORK

36V 5.5A

Networked Power Amplifier with Dante

LOCKDANTEOPTHDMILINE

+

-

MIC GAIN

VOLUME

-10

0dB

AUDIO INPUTVOLUME

NPA100DA

+10

45mm

Key Features

•

Advanced network audio amplier with Dante Integration

• Supports 2x 50W @ 4 / 8 ohm, 1x 100W @ 4 / 8 ohm or 70 / 100V

constant output for multiple speakers with longer cable runs

• Supports power via PoE++ on Dante LAN connection or Local

power supply*

• Dual network option - Independent Dante and LAN control ports

or combined to a single LAN port

• Audio inputs include:

- 2ch Dante / AES67 audio input

- HDMI ARC with CEC volume control

- MIC audio input with phantom power and auto-ducking

- 2ch Analogue audio input – unbalanced & balanced

- 1x Optical audio input

• Audio outputs include:

- 2ch Dante / AES67 audio output

- 2ch variable/xed analogue output, balanced / unbalanced

- 1x LFE sub-woofer output

• Independent gain control for input channels

• DSP with 31 band EQ with + / -10dB and audio delay

• Local 12V input trigger for automated power control

• Control via front panel, IR, RS-232 and IP

• Auto standby mode with signal sensing

• In-built web gui for setup and control

*Amp power limited when using PoE++ or PoE+
