KXX-100_ii_230228 Pg 1

1

K10-100(SQ)/101(SQ)/102(SQ)/103(SQ),

K30-100(SQ)/101(SQ)/102(SQ)/103(SQ)

K51-100(SQ)/101(SQ)/102(SQ)/103(SQ),

K50-100/101/102/103 & K80-100/101/102

Kitchen/Prep Pull-Down Faucet Installation Instructions

IMPORTANT: Read all instructions prior to installation and provide copy of instructions to consumer.

Operating Specifications:

Recommended Supply Pressure: 20 to 70 psi

*†

* Operating pressures between hot and cold supplies should vary no more than 30 psi.

† If water pressure exceeds 70 psi, install a Pressure-Reducing Valve (PRV).

INSTALLING TO SINK/DECK

•Place BASE (2) with O-RING (3) onto BODY (1)

•Slide INLET HOSES (4) and SPRAY-HOSE (5)

through sink/deck hole

•From underside slide SPACER (6a), in necessary,

MOUNT (6) and NUT (7) onto SHANK (1a);

loosely tighten NUT (7)

•From topside position BODY (1) with handle on

right side as shown and from underside securely

tighten NUT (7)

Position MOUNT (6)

to prevent rubbing of

SPRAYER HOSE (5)

CALIFORNIA FAUCETS RECOMMENDS THAT ALL PLUMBING PRODUCTS BE INSTALLED

BY A LICENSED PROFESSIONAL

Ø1-3/8”

IMPORTANT:The recommended sink/deck through-hole shall

be Ø1-3/8”. Maximum sink/deck thickness should no greater than

2-1/4”

IMPORTANT: Based on sink/deck thickness the use of SPACER

(6a)needs to be determined. If thickness is LESS than ½” use

SPACER (6a), if GREATER than ½” use only MOUNT (6).

IMPORTANT: Position MOUNT (6) so that SPRAY-HOSE (5)

does NOT rub against MOUNT (6) when SPRAYHEAD (8) is

pulled.
