Seite 1/2
BT1-D016-A-ENG 1/2© 2022.10 CANON INC.
MOUNTING AND CONNECTING
1. Loosen the large and small lock knobs of the clamper supplied with the focus
demand, and then mount the clamper to the pan handle of the tripod.
2. After mounting the clamper to the pan handle, tighten the large and small lock
knobs to secure the clamper.
3. Mate the rose joint of the focus demand with the rose joint of the clamper. Then
tighten the mounting knob of the clamper to rmly secure the focus demand.
4. Plug the demand cable into the connector of "TO SERVO CONTROL" on the
lens, and the other side into the connector of the focus demand.
OPERATION AND FUNCTION
[ Focusing operation ]
Turning the operation knob on the focus demand brings the object into focus.
[ Changing the focus direction ]
The direction of far or near can be switched by shifting the reverse switch on the
focus demand.
The factory default setting is to focus on a farther object when turned clockwise
as viewed from the operation knob side.
[Selecting the focus characteristics curve]
The focus characteristics curve selector switch on the focus demand can be
used to select one of the focus characteristics from the following three modes.
Standard mode
Standard characteristics where the focus lens
group is moved almost linearly, relative to the
operation knob rotation angle.
Far mode
Focusing resolution for farther objects is
intentionally increased. This enables ne and
easy adjustment work for farther objects near
to innity.
Near mode
Focusing resolution for closer objects is
intentionally increased. This enables ne and
easy adjustment work for closer objects near
to M.O.D.
PRODUCT LIST
Make sure all of the following items are included in the packing box. If you nd
any item missing, please contact your dealer.
・
Focus Demand
・
Clamper
（
CR-30
）
・
Demand Cable
・
Operation Manual "Before Using The Product"
・
Operation Manual "Regulations"
Before using the product, make sure to read the "GENERAL SAFETY INFORMATION"
and be sure to use the product correctly.
Thank you for purchasing a focus demand FDJ-S01.This focus demand FDJ-S01 is
an accessory used to perform focus servo operations of a box type lens. The focus
can be operated remotely by using this demand.
Lens Accessory
Focus Demand
FDJ-S01
OPERATION MANUAL
This product comes with the following documents:
• Operation Manual "Before Using The Product"
（
Included with the product
）
• Operation Manual "Regulations"
（
Included with the product
）
• Operation Manual
（
Web
）
(Unit: mm)
VIEW A
φ80
30
A
φ72
60°
59
97
84
50
15°
7 7
Rose Joint
Connector to Lens
Operation Knob
Index Pin
Focus Characteristics Curve Selector Switch
Reverse Switch
[
External view
]
Knob Position
Focus Position
M.O.D.
Infinity
Standard Mode
Near Mode
Far Mode
